- Page 1 WMP601W Washing Machine User's Manual Document Number 2820522884/ 18-04-12.(8:06)
- Page 2 Please read this user manual first! Dear Customer, Thank you for prefering an Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important instructions for safety and 5 Operating the product environment 5.1 Control panel ..... . .19 1.1 General safety . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will • Unplug the product when not in use. help protect from risk of personal injury or property • Never wash the product by spreading or pouring damage. Failure to follow these instructions shall water onto it! There is the risk of electric shock! void any warranty. -
Page 5: Children's Safety
Important instructions for safety and environment 1.3 Children's safety 1.6 Compliance with WEEE Directive • Packaging materials are dangerous to children. This appliance’s packaging material is Keep packaging materials in a safe place away recyclable. Help recycle it and protect from reach of the children. the environment by dropping it off in • Electrical products are dangerous for the the municipal receptacles provided for... -
Page 6: Your Washing Machine
Your washing machine 2.1 Overview 1- Power cable 5- Adjustable feet 2- Top panel 6- Loading door 3- Control panel 7- Detergent drawer 4- Filter cap 8- Drain hose 6 / 36 EN Washing Machine / User‘s Manual... -
Page 7: Package Contents
Your washing machine 2.2 Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronical water shut-off a- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual... -
Page 8: Technical Specifications
Your washing machine 2.3 Technical specifications Models (EN) WMP601W Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Electrical input (V/Hz) 230 V / 50Hz Total current (A) Total power (W) 2200 Spin speed (rpm max.) -
Page 9: Installation
Installation 3.2 Removing packaging Refer to the nearest Authorised Service Agent for installation of the product. To make the product reinforcement ready for use, review the information in the user Tilt the machine backwards to remove the manual and make sure that the electricity, tap packaging reinforcement. -
Page 10: Connecting Water Supply
Installation 3. Attach the plastic covers supplied in the User WARNING: Ensure that the cold and hot Manual bag into the holes on the rear panel. (P) water connections are made correctly when installing the product. Otherwise, your laundry will come out hot at the end of the washing process and wear out. -
Page 11: Adjusting The Feet
Installation 1. Loosen the lock nuts on the feet by hand. 2. Adjust the feet until the product stands level and balanced. • To prevent flowing of dirty water back into the machine and to allow for easy discharge, do not immerse the hose end into the dirty water or do not drive it in the drain more than 15 cm. - Page 12 Installation Electrical requirements Important Before you insert the plug into the wall socket Fitting a different plug make sure that the voltage and the frequency As the colours of the wires in the mains lead shown in the rating label corresponds to your of this appliance may not correspond with the electricity supply.
-
Page 13: Preparation
Preparation 4.1 Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying Suitable for No Iron Do not dry- Sensitive / Do not dry Do not dry Symbols dryer clean Delicate dry with dryer DRYING Drying... -
Page 14: Preparing Laundry For Washing
Preparation 4.2 Preparing laundry for washing 4.3 Things to be done for energy saving • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons Following information will help you use the product will damage the machine. Remove the metal in an ecological and energy-efficient manner. pieces or wash the clothes by putting them in a • Operate the product in the highest capacity laundry bag or pillow case. -
Page 15: Correct Load Capacity
Preparation 4.7 Using detergent and softener Some water might have remained in the product due to the quality control When using detergent, softener, starch, processes in the production. It is not fabric dye, bleach or limescale remover harmful for the product. read the manufacturer's instructions on the package carefully and follow the suggested 4.5 Correct load capacity... - Page 16 Preparation Choosing the detergent type • If the liquid detergent has lost its fluidity, dilute it with water before putting in the detergent cup. The type of detergent to be used depends on the type and colour of the fabric. • Use different detergents for coloured and white laundry. • Wash your delicate clothes only with special detergents (liquid detergent, wool shampoo, etc.) used solely for delicate clothes.
- Page 17 Preparation Using starch • Add liquid starch, powder starch or the fabric dye into the softener compartment. • Do not use softener and starch together in a washing cycle. • Wipe the inside of the machine with a damp and clean cloth after using starch. Using bleaches • Select a programme with prewash and add the bleaching agent at the beginning of the prewash. Do not put detergent in the prewash compartment.
-
Page 18: Tips For Efficient Washing
Preparation 4.8 Tips for efficient washing Clothes Light colours and Delicates/Woolens/ Colours Dark colours whites Silks (Recommended (Recommended (Recommended (Recommended temperature range temperature range temperature range temperature range based based on soiling level: based on soiling based on soiling level: on soiling level: cold-40ºC) 40-90ºC) level: cold-40ºC) -
Page 19: Operating The Product
Operating the product 5.1 Control panel 1 - Programme Selection knob (Uppermost 4 - Spin Speed adjustment button position On/Off) 5 - Auxiliary Function buttons 2 - Programme Follow-up indicator 6 - Delayed Start button (in some models) 3 - Temperature Adjustment button 7 - Start / Pause button 5.2 Preparing the machine 2. -
Page 20: Additional Programmes
Operating the product • Synthetics • Hand Wash Use this programme to wash your woolen/delicate Use this programme to wash your synthetic clothes (shirts, blouses, synthetic/cotton blends, clothes that bear “not machine- washable” tags etc.). It washes with a gentle action and has a and for which hand wash is recommended. It shorter washing cycle compared to the Cottons washes laundry with a very gentle washing action programme. -
Page 21: Temperature Selection
Operating the product 5.7 Temperature selection Whenever a new programme is selected, the recommended temperature for the selected programme appears on the temperature indicator. To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually. If the programme has not reached the heating step, you can change the temperature without switching the machine to Pause mode. -
Page 22: Programme And Consumption Table
Operating the product 5.9 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C Cottons 2.00 1600 • • • • • Cold-90 Cottons 1.35 1600 • • • • • Cold-90 Cottons 0.70 1600 • • • • •... -
Page 23: Auxiliary Function Selection
Operating the product 5.10 Auxiliary function selection • Rinse Plus This function enables the machine to make Use the following auxiliary functions according another rinsing in addition to the one already made to your daily needs. Select the desired auxiliary after the main wash. -
Page 24: Starting The Programme
Operating the product 5.12 Child Lock 4. Press Start / Pause button. Previous delayed start time light turns off and next delayed start Use child lock function to prevent children from time light turns on after every 3 hours. tampering with the machine. Thus you can avoid 5. -
Page 25: Progress Of Programme
Operating the product 5.13 Progress of programme Changing the speed and temperature settings for auxiliary functions Progress of a running programme can be followed Depending on the step the programme has from the Programme Follow-up indicator. At reached, you may cancel or activate the auxiliary the beginning of every programme step, the functions;... -
Page 26: Quick User Guide
Quick User Guide 6.1 Preparing the machine 6.5 Canceling the programme 1. Make sure that the hoses are connected tightly. To cancel the programme, turn the Programme 2. Plug in your machine. Selection knob to select another programme. 3. Turn the tap on completely. Previous programme will be canceled. -
Page 27: Maintenance And Cleaning
Maintenance and cleaning 7.2 Cleaning the loading Service life of the product extends and frequently faced problems decrease if cleaned at regular door and the drum intervals. Residues of softener, detergent and dirt may 7.1 Cleaning the detergent drawer accumulate in your machine in time and may cause unpleasant odours and washing complaints. -
Page 28: Cleaning The Body And Control Panel
Maintenance and cleaning 7.3 Cleaning the body In addition, prior to transporting the machine and control panel (e.g., when moving to another house) and in case of freezing of the water, water may have to be Wipe the body of the machine with soapy water or drained completely. - Page 29 Maintenance and cleaning 3. Some of our products have emergency draining Discharging the water when the product does not hose and some does not have. Follow the steps have an emergency draining hose: below to discharge the water. Discharging the water when the product has an emergency draining hose: a.
-
Page 30: Troubleshooting
Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be canceled. (See “Cancelling the programme”) Water in the machine. • Some water might have remained in the product due to the quality control processes in the production. >>> This is not a failure; water is not harmful to the machine. There is water leaking from the bottom of the washing machine. - Page 31 Troubleshooting Washing takes longer time than specified in the manual.(*) • Water pressure is low. >>> Machine waits until taking in adequate amount of water to prevent poor washing quality due to the decreased amount of water. Therefore, the washing time extends. • Voltage might be low. >>> Washing time is prolonged to avoid poor washing results when the supply voltage is low.
- Page 32 Troubleshooting Washing performance is poor: Oily stains appeared on the laundry. • Regular drum cleaning is not applied. >>> Clean the drum regularly. For this, please see 7.2. Washing performance is poor: Clothes smell unpleasantly.(**) • Odours and bacteria layers are formed on the drum as a result of continuous washing at lower temperatures and/ or in short programmes. >>> Leave the detergent drawer as well as the loading door of the machine ajar after each washing.
- Page 33 Troubleshooting There is detergent left on the laundry. (**) • Excessive laundry was loaded in. >>> Do not load the machine in excess. • Wrong programme and temperature were selected. >>> Select the proper programme and temperature for the laundry to be washed. • Wrong detergent was used. >>> Select the proper detergent for the laundry to be washed. Too much foam forms in the machine.(**) • Improper detergents for the washing machine are being used. >>> Use detergents appropriate for the washing machine.
- Page 34 PRODUCT FICHE Complying Commission Delegated Regulation (EU) No 1061/201 Supplier name or trademark Beko Model name WMP601W Rated capacity (kg) Energy efficiency class Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.014 Energy consumption of the standard 60°C cotton programme at partial load 0.820 (kWh) Energy consumption of the standard 40°C cotton programme at partial load...
- Page 35 If you have purchased an extended guarantee please refer to the instructions contained within the extended guarantee agreement document. Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 600 4911 e-mail:service@beko.co.uk...
- Page 36 Guarantee Your new Beko product is guaranteed against the cost of breakdown repairs for twelve months from the date of the original purchase. What is covered? • Repairs necessary as a result of faulty materials, defective components or manufacturing defect. • The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse. • Cabinet or appearance parts, including knobs, flaps, handles or container lids.
