- Page 1 Whynter Compact Size 11,000 BTU Portable Air Conditioner Model # : ARC-115WG Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before using this product. Keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
Table of Contents PAGE 3 - 4 SAFETY PRECAUTIONS PREPARATION DESIGN NOTICE EXHAUST HOSE INSTALLATION CHOOSING THE RIGHT LOCATION AMBIENT TEMPERATURE RANGE FOR UNIT OPERATION TECHNICAL DATA ACCESSORIES 7 - 8 WINDOW KIT INSTALLATION FILTER INSTALLATION AND DRAINAGE CONTROL PANEL OPERATION INSTRUCTIONS 9 - 11 REMOTE CONTROL... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Read Safety Precautions Before Operation and Installation To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. •... - Page 4 Do not press the buttons on the control panel with anything other than your fingers. Do not remove any fixed covers. Contact Whynter Customer Support if this unit if it is not working properly, or if it has been •...
-
Page 5: Preparation
PREPARATION All illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The actual shape shall prevail. The unit can be controlled by the unit control panel alone or with the remote controller. 1. Control Panel 2. -
Page 6: Ambient Temperature Range For Unit Operation
SACC is the representative value of Seasonally Adjusted Cooling Capacity, in Btu/h, as determined in accordance with the DOE test procedure at title 10 Code of Federal Regulations (CFR) 430, subpart B, appendix CC and applicable sampling plans. Model ARC-115WG Operation Modes: Cool / Fan / Dry... -
Page 7: Accessories
ACCESSORIES ACCESSORY IMAGE ACCESSORY DESCRIPTION QUANTITY 1. Exhaust hose 2. Connector (to the window kit) 3 pieces 3. Connector (to the unit) 1 piece Cover Window slider kit with (2) screws and (2) nuts 1 set Remote Control 1 piece WINDOW KIT INSTALLATION 1. -
Page 8: Filter Installation And Drainage
FILTER INSTALLATION AND DRAINAGE WARNING: NEVER OPERATE THE AIR CONDITIONER WITHOUT THE AIR FILTER Your Whynter portable air conditioner is equipped with a washable filter. This washable filter removes large particles such as dust, pet hair and dander. WATER DRAINAGE The dehumidifying capacity of this unit is 87 pints per day. -
Page 9: Control Panel
Note: If any other error code appears on the display, unplug the air conditioner and allow it to sit undisturbed for 5 minutes. If the error code persists when the unit is plugged back in, please contact Whynter Customer Support. - Page 10 OPERATION INSTRUCTIONS SWITCHING ON/OFF THE AIR CONDITIONER The appliance can be switched ON or OFF by pressing the POWER button on the control panel or the ON/OFF button on the remote control COOLING MODE In this mode, the air conditioner cools and dehumidifies the room. To activate this function mode, press the MODE button until the COOL indicator light comes on.
-
Page 11: Remote Control
OPERATION INSTRUCTIONS SLEEP MODE In this mode, the air conditioner gradually increases the set temperature in cooling mode, decreases the noise level and conserves energy. The temperature will then increase by another 1°C/ 1°F after an additional 30 minutes. This new temperature will remain the same for 7 hours. -
Page 12: Care And Maintenance
• DO NOT wash the unit under running water. Doing so causes electrical danger. • DO NOT operate the portable air conditioner if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord. Contact Whynter Customer Support for more information. UNIT CLEANING •... -
Page 13: Tips
• Call for service. Only authorized per- sonnel should replace damaged power cord or power plug • Press the Reset button on the L.C.D.I. power plug • Drain water from the air conditioner • Possible loose internal connection. • Please contact Whynter for service. - Page 14 Then cooling will resume. • Possible loose internal connection. • Please contact Whynter for service. • Clean the air filters The air coming out of the unit is • The filters are dirty or obstructed •...
-
Page 15: Warranty
HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PUR- POSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY.
