Summary of Contents for Joerns Healthcare Bari10A
- Page 1 Joerns Healthcare User-Service Manual Joerns Model Bari10A ® Bariatric Bed To avoid injury, read user’s manual before using bed. leading bed evolution...
- Page 2 Warning: Possible Fire Hazard. Use nasal mask any replacement parts not manufactured, marketed, or ½ bed tent oxygen administering equipment. or provided by Joerns Healthcare on any Joerns Oxygen tent should not extend below Mattress bed. Use of unapproved replacement parts may Support Platform.
- Page 3 To prevent injury to resident/patient connected Thank you and congratulations for choosing the to intravascular or intercardial medical equipment, Joerns Bari10A bed. Joerns beds are developed alternate measure must be implemented to equalize with safety, comfort and convenience of both the potential between Mattress Support Platform and resident/patients and caregivers in mind.
-
Page 4: Table Of Contents
Therefore, compliance is the responsibility of the facility. As the leading manufacturer of long-term care beds and a frontrunner in addressing this critical issue, Joerns Healthcare can offer you the expertise, assistance and products to bring your facility into compliance. www.joerns.com | info@joerns.com... -
Page 5: Features & Specifications
Bari10A Model Features and Classifications UL 60601-1 Specifications CAN/CSA C22.2 NO.601.1 IEC 60601-2-38 Joerns Bari10A Standard Features CAN/CSA C22.2 NO 601.2.38 ® • Fully articulated Mattress Support Platform with Environmental Conditions independent back and knee movement, up/down adjustments, Trendelenburg and Reverse Operating Conditions Trendelenburg positioning. -
Page 6: Assembly
Actuator battery backup is not user- serviceable. If service is required, contact Joerns Healthcare Technical Support at 800-966-6662. Lockout Control Activate Selective Function Lockout on bed Frame, to keep resident/patient from operating Actuators with Pendant. -
Page 7: Bed Operation
Bariatric Beds ® Bari10A Model Bed Operation Pendant Control Operation Your Bari10A bed comes standard with Initial Start Up Pendant Control (Figure 4). Resident/patient After positioning bed, always lock all casters. and staff can use the Pendant to adjust all... - Page 8 To lock/unlock functions, rotate switch until it clicks into position. Side Rails/Assist Devices Figure 7 Bari10A has one Head end Side Rail and one Foot end Side Rail on both sides of bed (Figure 7). Side Rails are attached and operated by Latch Hinge mechanism.
- Page 9 Joerns Bariatric Beds ® Bari10A Model Casters All (4) Casters securely lock bed in place. All Casters have full swivel/rotation locking in any position. Simply push Caster Lock Lever (Figure 9) down to lock and up to unlock (Figure 10).
- Page 10 Joerns Bariatric Beds ® Bari10A Model Warning: Possible Equipment Damage. Prior to Mattress Support Platform Width Extenders use of the MSP Length Extender, the Frame Length The four Mattress Support Platform (MSP) Extender must be fully extended and latched. Failure sections each have a 6"...
-
Page 11: Accessories
• Always plug bed back into power outlet so that it is continuously charging. Accessories Mattress Bari10A Bed may be equipped with BariMatt 1000 6.5" foam mattress (Figure 18, p.12). Mattress designed as separate sections, which fit together on Mattress Support Platform in different arrangements: narrow, sides extended or, length extended. - Page 12 Joerns Bariatric Beds ® Bari10A Model Figure 18 www.joerns.com | info@joerns.com...
-
Page 13: Scale System
Joerns Bariatric Beds ® Bari10A Model Scale System Bari10A bed is equipped with Scale System, fully integrated within Foot Panel (Figure 19). Scale System Features (Figure 20) Resident/patient’s weight is displayed on a 16-character dot matrix liquid crystal display with LED backlighting. - Page 14 Joerns Bariatric Beds ® Bari10A Model NOTE - SEE SHEET 2 OF 2 FOR TWO HIDDEN KEYS 7.42" Scale System Weight Freeze Weight Lb/Kg Change Functions and Resume Mode Mode Weighing Procedures zero Figure 21 .06 R. TYP. 4 Caution: 5th Wheel must be disengaged to obtain an accurate resident/patient weight.
- Page 15 Do not tamper with for any reason. 248.7 251.4 Re-calibration is generally not required, but should be verified periodically to ensure 497.4 502.6 accuracy. Joerns Healthcare recommends 746.2 753.9 checking calibration check once every 12 994.9 1000 1005.1 months, or as your maintenance policy requires.
-
Page 16: Cleaning, Inspection & Maintenance
Storage To achieve maximum usage and longest life Store in a clean dry area. for your Bari10A bed, follow all warnings and Plug bed Power Cord into grounded hospital- cautions within this manual and maintain grade electrical outlet. Actuator Control System your bed with care, as outlined below. -
Page 17: Lubrication Servicing
Joerns Bariatric Beds ® Bari10A Model Lubrication Servicing Recommended Lubricants Oil: Use 3-In-One oil or equivalent. ® Grease: Use Super Lube synthetic grease or ® equivalent. Oiling Points Keep pins and bolts oiled (sample indicated by arrows in Figure 24). - Page 18 If beeping occurs while raising or lowering bed, Hi-Low Actuators may have lost synchronization. Lower bed to lowest position. Release Bed Down button. Press and hold Bed Down button for five seconds to recalibrate synchronization. If problems persist, contact Joerns Healthcare Technical Support at 800-966-6662. www.joerns.com | info@joerns.com...
-
Page 19: Troubleshooting
Bed movement with all Braking mechanisms may be worn Remove bed from use and contact casters locked. on one or more casters. Joerns Healthcare Technical Support at 800-966-6662. Scale System display Batteries are dead. Replace all six batteries is blank after On button Unit is defective. - Page 20 Joerns Bariatric Beds ® Bari10A Model Appendix A - Actuator Wiring Diagram www.joerns.com | info@joerns.com...
- Page 21 Joerns Bariatric Beds ® Bari10A Model Appendix B – Scale System Wiring Diagram www.joerns.com | info@joerns.com...
- Page 22 Joerns Bariatric Beds ® Bari10A Model Notes: www.joerns.com | info@joerns.com...
- Page 23 Joerns Bariatric Beds ® Bari10A Model Notes: www.joerns.com | info@joerns.com...
-
Page 24: Warranty
90 days after date of delivery. Intended product lifetime is 15 years. Joerns Healthcare Inc. 5001 Joerns Drive, Stevens Point WI 54481 (P) 800.826.0270 | (F) 800.457.8827 www.joerns.com | email: info@joerns.com © 2008 Joerns Healthcare Inc. | Part# 6110033 RevF | DCO# 08-0411...
