- Page 1 Joerns Healthcare User-Service Manual Joerns EasyCare Bed Platform ® ® Model ECS To avoid injury, read user’s manual before using. EasyCare 3 EasyCare 5 EasyCare 7 EasyCare 9 leading bed evolution...
-
Page 2: Important Precautions
State and Federal guidelines. Joerns Healthcare potentially resulting in injury or death. recommends the use of a mattress with minimum dimensions of 35 inches wide and 6 inches deep. -
Page 3: Easycare
IEC 60601-1-2. Radio transmitting any replacement parts not manufactured, marketed equipment, cellular phones or similar electronic or provided by Joerns Healthcare on any Joerns devices, used in proximity of bed, may affect bed bed. Use of unapproved replacement parts may performance. -
Page 4: Table Of Contents
As the leading manufacturer of long-term care consult the FDA website: www.fda.gov/cdrh/beds beds and a frontrunner in addressing this critical issue, Joerns Healthcare can offer you the I.D. Label Symbol Definition expertise, assistance and products to bring your facility into compliance. -
Page 5: Features & Specifications
Joerns EasyCare Bed Platform ® ® Model ECS Features and Specifications Accessories And Options 76", 80" and 84" Joerns Mattresses ® Joerns End Panels Standard Features 76" or 80" Sleep Surface F14SC Assist Device Set Travel Range: F025 Assist Handle •... -
Page 6: Assembly
Joerns EasyCare Bed Platform ® ® Model ECS Assembly Head Panel Foot Panel Bracket-10.5" Bracket-6.9" Installation Of Head and Foot Panels (For more information refer to Bed Panel Installation Sheet) Tools required: Phillips head screwdriver Head Panel Installation: 1. The head panel has a label on back. 2. -
Page 7: Easycare
Joerns EasyCare Bed Platform ® ® Model ECS Installation of Mattress Stop (Figure 6) Mattress Stop is designed to help keep mattress IV Socket from sliding laterally on the mattress support platform. Installation Steps 1. Locate the holes in the inside tube at the foot end of the mattress support platform. -
Page 8: Operation
Joerns EasyCare Bed Platform ® ® Model ECS EasyCare 9 (Figure 11) Operation ® 1. Mount the foot panel on the bed as indicated Pendant Operation in previous instructions. 2. Unscrew the cap located under the bed frame EasyCare 3, 5 and 7 at the foot end (Figure 12), and secure the Your Joerns EasyCare 3, EasyCare 5, or EasyCare... - Page 9 Joerns EasyCare Bed Platform ® ® Model ECS EasyCare ® 1. Your EasyCare 9 bed comes standard with a pendant (Figure 18). The pendant plugs into a port under either side of the seat pan. 2. Unscrew the cap (Figure 19) and insert the cable connector, with the arrow facing up into plug (Figure 20).
- Page 10 Joerns EasyCare Bed Platform ® ® Model ECS Staff Control Panel Operation (Optional) EasyCare 3, 5 and 7 (Figure 23) ® The Staff Control Panel allows caregivers to lock out all of the bed functions individually. Caregivers can also operate the bed from this panel without walking to side of the bed.
- Page 11 Joerns EasyCare Bed Platform ® ® Model ECS UltraLock System EasyCare 7 and 9 ® The Joerns UltraLock feature provides roll at any ® height functionality to the EasyCare 7 and EasyCare 9 bed frame. • The EasyCare 7 and EasyCare 9 beds are equipped with a single UltraLock.
-
Page 12: Servicing
Joerns EasyCare Bed Platform ® ® Model ECS EasyLift Leg Positioner Operation EasyCare 5, 7 and 9 ® 1. To raise: Grasp the bed’s foot deck and raise to the desired position (Figure 30). 2. To lower: Grasp the foot end of the bed’s deck and raise ½-inch to ¾-inch above present Figure 30 notch, then lower gently;... - Page 13 Joerns EasyCare Bed Platform ® ® Model ECS EasyCare ® Warning: Possible Shock Hazard. Unplug the Control Box from the wall outlet before performing any maintenance or service to the Control Box. Motor And Control Box Information Figure 33 Cord and Socket Identification (Figures 33 and 34) 1.
- Page 14 Joerns EasyCare Bed Platform ® ® Model ECS To Remove Actuator To Remove AC Power Cable Recommended Tools: Screwdriver, Hammer, Recommended Tools: Small Screwdriver, Masking Tape, Zip Ties Masking Tape, Zip Ties, 5/16" Nut Driver 1. Identify the actuator to be replaced. 1.
-
Page 15: Troubleshooting
Joerns EasyCare Bed Platform ® ® Model ECS 1. Switch the pendant with a new pendant or one Troubleshooting from a bed that is functioning normally. 2. If these steps fail to resolve the problem, call Any loss of electrical function should be investigated Technical Support at 800-826-0270. -
Page 16: Accessories
Joerns EasyCare Bed Platform ® ® Model ECS Accessories Drainage Bag Holder Warning: Possible BioHazard. Prior to use, consult All Accessories the Drain Bag manufacturer’s installation and use instructions. Failure to do so could result in a bag Warning: Possible Injury Or Death. Injury puncture, resulting in a potential BioHazard. - Page 17 Joerns EasyCare Bed Platform ® ® Model ECS Trapeze (Figure 36) 1. We recommend using the Joerns Trapeze with ® the Joerns Trapeze Adapter. 2. Install the Trapeze assembly according to manufacturer’s directions included with the Trapeze. Trapeze Adapter (Figure 37) 1.
- Page 18 Joerns EasyCare Bed Platform ® ® Model ECS Drainage Bag Holder (Figure 39) Bed Transport Bar (Figure 40) 1. The Drainage Bag Holder is designed as 1. The Bed Transport Bar is designed to ease an attachment point for items such as urine moving the EasyCare Bed, particularly when it ®...
- Page 19 Joerns EasyCare Bed Platform ® ® Model ECS Battery Back-up Battery Backup Includes: • Charger with Power Cord PN#12160300 (with Cord Clip) • Battery with Cable PN#12160311 • Wall Mount Bracket PN#12160301 (with two screws) • User Instructions PN#6150192 Battery Charger 1.
-
Page 20: Warranty
