Summary of Contents for Crestron CNIRT-32
-
Page 3: Table Of Contents
CRESTRON CNRFT/CNIRT DESCRIPTION... 1 Functional Description... 1 CNRFT-32A/-48A... 1 CNIRT-32A/-48A... 1 Physical Description... 2 Configuration Differences ... 2 LEADING SPECIFICATIONS ... 3 CONTROLS AND INDICATORS... 4 Controls... 4 Indicators... 4 INSTALLATION/SETUP ... 4 PROGRAMMING ... 6 TEST/TROUBLESHOOTING... 7 FURTHER INQUIRIES... 8 SYNTAX ... -
Page 5: Description
ID code setting have been eliminated and replaced by a software utility program available from CRESTRON's Workshop. The radio-frequency (RF) code packets have been updated to include error detection for higher reliability reception. The new improved one-way wireless panels must be used with CRESTRON's new CNRFGWA or CNIRGWA receiver. -
Page 6: Physical Description
CRESTRON CNRFT/CNIRT Physical Description CNRFT-32A/48A and CNIRT-32A/48A electronic hardware is housed in a high-impact molded plastic enclosure (refer to figures 1 and 2 for front and back views, respectively ). The button array on the printed circuit board is covered by a customized button panel. All button panels include custom engraving, colored button caps, choice of button configurations, and panel finishes. -
Page 7: Leading Specifications
CRESTRON CNRFT/CNIRT LEADING SPECIFICATIONS: Table 2 provides a summary of leading specifications for the wireless transmitters. Dimensions and weight are approximations rounded to the nearest tenth unit. SPECIFICATION Battery CRESNET II Workshop CRESNET II Operating System CNRFT-32A & CNIRT-32A Dimensions & Weight CNRFT-48A &... -
Page 8: Controls And Indicators
IR ID. There are 254 possible two-digit hexadecimal alphanumeric codes ranging from 01 to FE. The CNRFT/CNIRT ID CODE is factory set to 11, but may be changed from a PC via CRESTRON's CRESNET II Workshop. An ID CODE may need to be changed if more than one transmitter is placed on the network. - Page 9 CRESTRON CNRFT/CNIRT 3. From the MAIN MENU, highlight Utilities and depress ENTER. The UTILITY MENU, illustrated in figure 4, appears on the display. CRESNET Workshop v5.0 MAIN MENU SIMPL RIPE Sort IR drv Utilities Quit Enter SIMPL (Symbol - Intensive - Master - Programming -...
-
Page 10: Programming
CRESTRON CNRFT/CNIRT 10. With a finger over the probe to hold it in place, lift and rotate transmitter so that the red LED located above the button panel is visible. 11. From the PC, type the two-digit hexadecimal ID CODE. -
Page 11: Test/Troubleshooting
Define Net Panel Detail TEST/TROUBLESHOOTING: Table 3 provides corrective action for possible trouble situations. If further assistance is required, please contact a CRESTRON technical support representative. TROUBLE POSSIBLE CAUSE(S) LED on unit does not No battery in unit or battery is dead. -
Page 12: Further Inquiries
Two or more receivers are too close together. Wrong transmitter in use. FURTHER INQUIRIES: If after reviewing this Operations Guide you still have additional questions, please contact a CRESTRON technical support representative by dialing (888) CRESTRON [(888) 273-7876] or (201) 894-0660. R E M O T E... -
Page 13: Syntax
CRESTRON CNRFT/CNIRT SYNTAX: The following syntax codes are provided for compatibility purposes only. NET.ID <10 o FE>: CNRFGW TRANSMITTER <RF IDCODE >: CNRFT \ID # and transmitter type. i1 = <signal name> i2 = <signal name> i3 = <signal name>...
