CRESTRON CNRFT/CNIRT

DESCRIPTION:

Functional Description

The CNRFT series of portable RF wireless controls is designed to operate with the CRESNET II system
with the use of a wireless receiver such as the CNRFGW network unit. The CNIRT series of infra-red
controls operates with the CNIRGW network unit.
CNRFT and CNIRT transmitter may also communicate with older systems having a CNRFT-1W, CNRF-
2W, or CNIRR-1W wireless receiver connected to a CNWCI-4 Wireless Module.

Physical Description

Panels are pre-mounted in consolettes of high-impact molded plastic with black lacquer or oak wood trim.
Custom engraving, choice of colored button caps, panel finishes and button configurations, and the
omission of unused buttons are all standard.

Configuration Differences

The CNRFT/CNIRT 32 and 48 button models can also emulate the earlier CTW series of portable
transmitters. The CNRFT-32 and CNIRT-32 transmitters can emulate the CTW-32 transmitters, while
the CNRFT-48 and CNIRT-48 transmitter can emulate the CTW-48 transmitters. A CNRFT or CNIRT
series transmitter will emulate a CTW series transmitter using the same ID CODE settings when the ID
CODE is set to 00 through 0F. When a CTW series transmitter is being emulated, that model must be
specified (not a CNRFT) in the SIMPL-C TRANSMITTER statement. If you are programming in SIMPL-I,
you must inform SIMPL-I you are using a CTW series transmitter.

LEADING SPECIFICATIONS:

CRESNET II Workshop Version 4.00 or later.
CRESNET II Operating System SR30160.OPS or later.

INSTALLATION/SETUP:

Identity Code

Each unique transmitter communicating with the receiver requires the setting of an identity code (ID
CODE). ID CODES are two-digit hexadecimal numbers from 00 to 7F. To set the ID CODE, use the two
rotary switches accessible through the battery compartment. Each rotary switch is numbered 0 through
F. Use a small screwdriver to point the arrow in the center of the switch to the desired number or letter.
The left rotary switch represents the most significant digit.
R E M O T E
C O N T R O L
S Y S T E M S
1
Specifications subject to change without notice.
One-Way Wireless Panels
DOC. 8051B
