- Page 1 Crestron CAT5 Wiring Reference Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2004 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron CAT5 Wiring Introduction ... 1 Electrical Measurements of CAT5E Wiring... 2 Installation Notes ... 2 CAT5 Pin and Color Specifications... 3 CAT5 Cable Pairs ... 3 CAT5 Wiring EIA Specification TIA-568B... 4 CAT5 Wiring EIA Specification TIA-568A... 4 Audio Applications... 5 CNXRMCLV Balanced Audio Connector ... - Page 4 C2N-IADS Audio to CNX-BIPAD8 Audio Distribution Processor ...39 C2N-NPA8 Poll Accelerator LAN Connector ...40 The QuickMedia Transport System ...40 Crestron Certified Wire and Cable...43 Further Inquiries ...45 Glossary ...46 References...47 ii • Contents Crestron CAT5 Wiring Crestron CAT5 Wiring - DOC. 6137A...
-
Page 5: Crestron Cat5 Wiring
Generally, in a hub system every device must have a separate wire returning to a central point. CAT5 wire is typically four pairs of 24AWG solid copper wires, with each pair twisted about three times per inch. It can be supplied with or without a foil shield, and with various outer insulation materials. -
Page 6: Electrical Measurements Of Cat5E Wiring
Avoid periodic sags; vary the intervals if the cable must sag. • Do not bend CAT5 wire tightly around a corner; ensure that it bends gradually, so that a whole circle would be at least two inches in diameter. •... -
Page 7: Cat5 Pin And Color Specifications
(e.g., 10BaseT Ethernet uses pairs 2 & 3). The pin numbers indicate actual physical locations on the plug and jack. CAT5 Cable Pairs The CAT5 twisted cable pairs are color-coded; the pair colors depend on which EIA specification is used, TIA-568B or TIA-568A. CAT5 Pair Color Coding... -
Page 8: Cat5 Wiring Eia Specification Tia-568B
RJ-45 Jack Pinouts – Standard 568B CAT5 Wiring EIA Specification TIA-568A In the EIA specification TIA-568A CAT5 cable color/pin arrangement, the pairs remain the same, but the pin number assignment for the orange and green pairs change. -
Page 9: Audio Applications
NOTE: Balanced audio does not require a shield if the cable has good common mode characteristics (such as CAT5). Unbalanced audio signals are sent on a single wire, using ground as the reference for the signal. Ground wires are problematic because they can carry current when exposed to electromagnetic fields or when there is a voltage difference between the two connecting pieces of equipment. -
Page 10: Tps-Imc-Bv Balanced Audio Connector
This port provides audio input to the touchpanel and microphone output from the touchpanel. TPS-IMPC RJ-45 Connector Pinout (AUDIO) TPS-IMW Audio Connector 6 • Crestron CAT5 Wiring PIN # SIGNAL Mic out +... -
Page 11: Tps-2000L Balanced Audio Connector
Left In (-) Shield (S) PIN # SIGNAL Ground (S) Right Input (R+) Right Ground (R-) Left Input (L+) Left Ground (L-) Ground (S) Reference Guide + - + - S R R L L S Crestron CAT5 Wiring • 7... -
Page 12: C2N-Dap8 And C2N-Dap8Rc Balanced Audio Connector
Reference Guide C2N-DAP8 and C2N-DAP8RC Balanced Audio Connector C2N-DAP8RC RJ-45 Audio Connector C2N-TXM Audio Out Connector C2N-TXM AUDIO OUT Pinout 8 • Crestron CAT5 Wiring PIN # SIGNAL Left Audio Out + Left Audio Out - Right Audio Out +... -
Page 13: Balanced Audio Cable From Cnxrmclv To Tps-Imc, Tps-Imc-Bv, & Tps-Imw
Pin 1 Reference Guide TPS-IMC, TPS-IMC-BV PIN # AND TPS-IMW (AUDIO INPUT) MINI CONNECTOR Audio In R + Audio In R - Audio In L + Audio In L - 1 2 3 4 5 6 Crestron CAT5 Wiring • 9... -
Page 14: Mic Cable Wiring From Tps-Imc, Tps-Imc-Bv, & Tps-Imw To Cnxrmclv
Reference Guide Mic Cable Wiring from TPS-IMC, TPS-IMC-BV, & TPS-IMW to CNXRMCLV TPS-IMC, TPS-IMC-BV and TPS-IMW Mini Connector (MIC OUT) to CNXRMCLV RJ-45 Connector (AUDIO) 10 • Crestron CAT5 Wiring FROM TPS-IMC, TPS-IMC- PIN # BV AND TPS-IMW (MIC OUT) -
Page 15: Balanced Audio Connection From Cnx-Bipad8 To Tps-2000L
TPS-2000L PIN # MINI CONNECTOR (MONO AUDIO) Audio In + Audio In - Ground/Shield Mic Out + Mic Out - Ground/Shield Video In + Video In - 1 2 3 4 5 6 7 8 Crestron CAT5 Wiring • 11... -
Page 16: Balanced Audio Connections From Tps-Imc-Bv To Cnx-Bipad8 (Mic And Audio)
CNX-BIPAD8 and TPS-IMC-BV. When connecting the CNX-BIPAD8 direct to the TPS touchpanel (not using the TPS-IMC-BV) using a standard CAT5 cable or Crestron TPS Audio cable, only the audio on the right channel will operate. 12 • Crestron CAT5 Wiring... -
Page 17: Audio From C2N-Dap8Rc To Cnxrmclv
Left Audio Out - Right Audio Out + Right Audio Out + Left Audio In + Left Audio In - Right Audio In + Right Audio In - 1 2 3 4 5 6 7 8 Pin 1 Crestron CAT5 Wiring • 13... -
Page 18: Audio From Cnxrmclv To C2N-Dap8
Reference Guide Audio from CNXRMCLV to C2N-DAP8 14 • Crestron CAT5 Wiring CNXRMCLV RJ-45 Connector (AUDIO) PIN # SIGNAL Left Audio Out + Left Audio Out - Right Audio Out + Right Audio Out - Left Audio In + Left Audio In -... -
Page 19: Audio From Cnx-Bipad8 To C2N-Dap8
Left Audio Out - Right Audio Out + Right Audio Out - Left Audio In + Left Audio In - Right Audio In + Right Audio In - 1 2 3 4 5 6 7 8 Pin 1 Crestron CAT5 Wiring • 15... -
Page 20: Audio And Mic Connections From Tps-Imc-Bv To Cnxrmclv
CNXRMCLV RJ-45 Connector (AUDIO) via Custom Cable NOTE: Connecting the TPS-IMC-BV to the CNX-RMCLV does not work when using a standard CAT5 cable for balanced audio. You must make the custom cable in the preceding table. 16 • Crestron CAT5 Wiring... -
Page 21: Audio And Mic Connections To Touchpanel Direct From Cnxrmclv
CNXRMCLV, and obtain both channels of audio to the TPS touchpanel, is to use the TPS-IMC or TPS-IMW and connect the CNXRMCLV directly to the mini connector labeled AUDIO INPUT, using a CAT5 cable. Refer to page 9 for a diagram. -
Page 22: Balanced And Unbalanced Audio And Video Applications
Balanced Audio and Balanced Video Connections from CNXRMCLV RJ-45 Connectors (AUDIO and VIDEO OUT) to TPS-2000L Mini Connector FROM PIN # Audio CAT5 Video CAT5 18 • Crestron CAT5 Wiring CNXRMCLV (AUDIO & VIDEO OUT) RJ-45 CONNECTORS Audio Out + (from RJ-45 Audio connector) - Page 23 Reference Guide – DOC. 6137A AUDIO VIDEO 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Pin 1 Pin 1 Reference Guide 1 2 3 4 5 6 7 8 Crestron CAT5 Wiring • 19...
-
Page 24: Unbalanced Audio Input, Video Input, And Mic Output For A Tps-2000L
Output for a TPS-2000L Unbalanced Audio and Video Connections for a TPS-2000L Mini Connector For unbalanced audio input single-ended connections, connect the signal (-) terminal, and the ground/shield terminal, to the input ground/shield. 20 • Crestron CAT5 Wiring Audio Left Hot Audio Input... -
Page 25: Balanced Video Applications
Level 2 - Level 4 + Level 4 - Reference Guide 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Crestron CAT5 Wiring • 21... -
Page 26: Tps-Imw Net/Video Connector
TPS-IMW NET/Video Connector NET/VIDEO 10-Pin RJ-45 Connector TPS-IMC-BV Balanced Video Connector TPS-IMC-BV RJ-45 Connector Pinout (BALANCED VIDEO) TPS-2000L Video and Audio Connector TPS-2000L Mini 8-Pin Connector Pinout 22 • Crestron CAT5 Wiring PIN # SIGNAL DESCRIPTION +24V Power (Network) Ground (Network) -
Page 27: Tps-3000L/Tps-3100L/4000L Ntsc/Pal Balanced Video Input Connector
SIGNAL Level 1 + Level 1 - Level 2 + Level 3 + Level 3 - Level 2 - Level 4 + Level 4 - Reference Guide 1 2 3 4 5 6 7 8 Crestron CAT5 Wiring • 23... -
Page 28: Balanced Video From Cnx-Pvid8 To C2N-Dap8Rc
Level 1 plus 2 = S-Video (Y on level 1 and C on level 2) Level 1 plus 2 plus 3 = Component Video (Y, P Level 4 = Composite Video (fixed compensation) or Digital Audio 24 • Crestron CAT5 Wiring CNX –PVID8 RJ-45 Connector C2N-DAP8RC RJ-45 Video IN... -
Page 29: Balanced Video From C2N-Dap8Rc To Cnx-Pbvr4
SIGNAL Level 1 + Level 1 - Level 2 + Level 3 + Level 3 - Level 2 - Level 4 + Level 4 - 1 2 3 4 5 6 7 8 Pin 1 Crestron CAT5 Wiring • 25... -
Page 30: Balanced Composite Video From Cnx-Pvid To Tps-2000L
Connect pin 8 of the TPS-2000L to the negative level on CNX-PVID. The following example shows level 1. Balanced Composite Video Connections from TPS-2000L Mini Connector to CNX-PVID RJ-45 Connector (ROOMS 1 – 8) 26 • Crestron CAT5 Wiring FROM PIN # CNX-PVID (ROOMS 1 - 8) -
Page 31: Balanced Composite Video From Cnx-Pvid To Tps-Imc-Bv
Crestron CAT5 Wiring Balanced Composite Video from CNX-PVID to TPS-IMC-BV Using a standard EIA-568B CAT5 cable, program the composite video to output from level 2 of the CNX-PVID. Set the switch labeled Bal/Coax to Bal on the TPS-IMC-BV. NOTE: Connection shown below is for Level 1 Output from CNX-PVID. -
Page 32: Balanced S-Video From Cnx-Pvid To Tps-Imc-Bv
Reference Guide Balanced S-Video from CNX-PVID to TPS-IMC-BV Using a standard EIA-568B CAT5 cable, program the S-video to output from level 2 of the CNX-PVID C (Chrominance) and level 1 for Y (Luminance). Set the switch labeled Bal/Coax to Bal on the TPS-IMC-BV. -
Page 33: C2N-Tfm And C2N-Ttvfm Am Radio Port
Crestron CAT5 Wiring C2N-TFM and C2N-TTVFM AM Radio Port AM Radio Port (RJ-45) NOTE: This connector is only used for interfacing with Crestron products specifically designed to work with this unit. It cannot be used for connections to Cresnet C2N-TAMWX AM/Weather Band Tuner... -
Page 34: C2N-Iif Intercom Interface
Reference Guide C2N-IIF Intercom Interface C2N-IIF Video (OUT) RJ-45 Connector C2N-IIF Audio (IN/OUT) RJ-45 Connector 30 • Crestron CAT5 Wiring PIN # SIGNAL Video + Video - Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected PIN #... -
Page 35: Audio Connections From C2N-Iif To C2N-Iads30X24 Intercom Audio Distribution System
RJ-45 CONNECTOR Audio IN L + Audio IN L - Not Connected Audio OUT L + Audio OUT L - Not Connected Not Connected Not Connected 1 2 3 4 5 6 7 8 Pin 1 Crestron CAT5 Wiring • 31... -
Page 36: Video Connections From C2N-Iif To C2N-Ivds24X24 Intercom Video Distribution System
Reference Guide Video Connections from C2N-IIF to C2N-IVDS24X24 Intercom Video Distribution System C2N-IIF Video (OUT) RJ-45 Connector to C2N-IVDS24X24 Video (IN) RJ-45 Connector FROM PIN 32 • Crestron CAT5 Wiring C2N-IIF VIDEO OUT RJ-45 CONNECTOR Video + Video - Not Connected... -
Page 37: Video Connections From C2N-Iif To Cnx-Pbvr4 Professional Balanced Video Receiver
Reference Guide TO PIN # CNX-PBVR4 VIDEO I/O RJ-45 CONNECTOR Video + Video - Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected 1 2 3 4 5 6 7 8 Pin 1 Crestron CAT5 Wiring • 33... -
Page 38: Audio Connections From C2N-Iif To Cnx-Pbar4 Professional Balanced Audio Receiver
Reference Guide Audio Connections from C2N-IIF to CNX-PBAR4 Professional Balanced Audio Receiver Audio from C2N-IIF RJ-45 Connector (AUDIO IN/OUT) to CNX-PBAR4 RJ-45 Connector (AUDIO IN) 34 • Crestron CAT5 Wiring FROM C2N-IIF PIN # AUDIO IN/OUT RJ-45 CONNECTOR Line Level MIC OUT +... -
Page 39: C2N-Ivds24X24 Intercom Video Distribution System
SIGNAL Video + Video - Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected Reference Guide 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Crestron CAT5 Wiring • 35... -
Page 40: C2N-Ivds Video To Tps-Imc-Bv Touchpanel Interface
C2N-IVDS Video to TPS-IMC-BV Touchpanel Interface C2N-IVDS Video (OUT) RJ-45 Connector to TPS-IMC-BV BALANCED VIDEO RJ-45 Connector FROM PIN # 36 • Crestron CAT5 Wiring SIGNAL TO PIN # Video + Video - 1 2 3 4 5 6 7 8... -
Page 41: C2N-Iads30X24 Intercom Audio Distribution System
C2N-IADS30x24 Intercom Audio Distribution System Audio (OUT) RJ-45 Connector (22 Connectors) NOTE: When connecting the IADS to a BIPAD8 via CAT5, make sure that the IADS audio out pins are connected to the BIPAD8 audio in pins, and the IADS audio in pins are connected to the BIPAD8 audio out pins. -
Page 42: C2N-Iads Audio To Tps-Imc-Bv Touchpanel Interface
Reference Guide C2N-IADS Audio to TPS-IMC-BV Touchpanel Interface Audio Connections fron C2N-IADS to TPS Interface Module FROM PIN # 38 • Crestron CAT5 Wiring C2N-IADS REMOTE AUDIO IN/OUT RJ-45 CONNECTOR Not Connected Not Connected Not Connected Audio OUT L +... -
Page 43: C2N-Iads Audio To Cnx-Bipad8 Audio Distribution Processor
Not Connected Not Connected Not Connected Audio In L + Audio In L - Not Connected Audio In R + Audio In R - 1 2 3 4 5 6 7 8 CNX-BIPAD8 ROOMS Pin 1 Crestron CAT5 Wiring • 39... -
Page 44: C2N-Npa8 Poll Accelerator Lan Connector
MediaManager installations. Routing CAT5E/UTP cable is less expensive and much simpler than routing multi- colored, multi-conductor coax cable. All Crestron products using the QuickMedia Transport System are capable of sending and receiving QuickMedia signals via standard CAT5E/UTP cable. Crestron recommends Belden Media-Twist cable, and Crescat-QM. - Page 45 The total accumulated skew from QM transmitter to QM receiver must not exceed 15 ns (nanoseconds). Crestron recommends a cable with a rating of less than or equal to 15 ns over its entire length.
- Page 46 Reference Guide QuickMedia Pin and Pair Assignment RJ-45 MALE CONNECTOR RJ-45 NUMBER 42 • Crestron CAT5 Wiring CAT5E WIRE COLORS PAIR ASSIGNMENT NUMBER RGB AND AUDIO White/Orange - RGB Red Orange + RGB Red White/Green - RGB Green Blue + Audio...
-
Page 47: Crestron Certified Wire And Cable
Crestron Certified Wire and Cable NOTE: Crestron wire may be purchased directly from Crestron (www.crestron.com). CRESNET - Cresnet Control Cable: Basic cable for interconnecting the Crestron Control Network. CRESNET – Cresnet Control Cable – Non-Plenum CRESNET – Cresnet Control Cable – Plenum CRESCAT: Basic Crestron Control Cable combined with a single CAT5E cable. - Page 48 Reference Guide CRESCAT-D – 2 CAT5E plus Cresnet Control Cable CRESCAT-Q: Basic Crestron Control Cable combined with a four CAT5E cables, for use with fully implemented media distribution systems. Applications include bi-directional balanced audio and video home automation and control, and Ethernet data network.
-
Page 49: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website (www.crestron.com) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 50: Glossary
Luminance: The black and white portion of a video signal which carries the information for brightness, darkness and contrast, plus the horizontal and vertical sync. Mbps, MegaBits Per Second: One million bits per second. 46 • Crestron CAT5 Wiring Crestron CAT5 Wiring Reference Guide - DOC. 6137A... -
Page 51: References
100 Mbps on unshielded twisted-pair cabling. References Category 5E information courtesy of: Reference Guide – DOC. 6137A Numeric • The Siemon Company • Southwire Cyber Technologies, Inc. • Hubbell-Premise.com • Microtest • LANshack.com • Acteon.net Reference Guide Crestron CAT5 Wiring • 47... - Page 52 Crestron Electronics, Inc. Reference Guide – DOC. 6137A 15 Volvo Drive Rockleigh, NJ 07647 11.04 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
