MiniOX
3000
®
• Oxygen Monitor
• Sauerstoff monitor • Monitor de Oxígeno
• Moniteur d'Oxygène • Monitore d'ossigeno
Operating Manual
Customer Service: 1-847-855-0800
Repair: 1-847-855-0800
Fax: 1-608-222-6028
Gebrauch sanweisung
Kundendienst: 1-847-855-0800
Durchwahl: 1-847-855-0800
Fax: 1-608-222-6028
Manual de Operación
Servicio al Cliente: 1-847-855-0800
Reparaciones: 1-847-855-0800
Fax: 1-608-222-6028
Manuel d'instructions
Service clientèle : 1-847-855-0800
Réparations : 1-847-855-0800
Téléfax : 1-608-222-6028
Manuale d'istruzioni
Assistenza al cliente: 1-847-855-0800
Manutenzione: 1-847-855-0800
Fax: 1-608-222-6028
FEDERAL (U.S.) LAW RESTRICTS THIS PRODUCT TO SALE BY OR ON THE ORDER OF A PHYSICIAN
NACH US-AMERIKANISCHEM RECHT DARF DIESES PRODUKT NUR VON EINEM ARZT ODER AUF DES-
SENANORDNUNG HIN VERKAUFT WERDEN
LA LEY FEDERAL (EE.UU.) LIMITA LA VENTA DE ESTE PRODUCTO A LA ORDEN DE UN MÉDICO
LA LOI FEDERALE (DES ETATS-UNIS) N'AUTORISE LA VENTE DE CE PRODUIT QUE PAR OU SUR L'ORDRE
D'UNMEDECIN
AI SENSI DELLE LEGGI FEDERALI DEGLI STATI UNITI, IL PRESENTE PRODOTTO VA VENDUTO SOLO DI-
ETROPRESCRIZIONE MEDICA
Manufactured by:
Hergestellt von:
Fabricado por:
Fabriqué par :
Prodotto da:
Ohio Medical Corporation
| 1111 Lakeside Drive | Gurnee, IL 60031 USA
®
1-847-855-0800 | www.ohiomedical.com
711449 (Rev.3) 02/2016

Advertisement

Table of Contents
loading

Related Manuals for Ohio Medical MiniOX 3000

Summary of Contents for Ohio Medical MiniOX 3000

  • Page 1 AI SENSI DELLE LEGGI FEDERALI DEGLI STATI UNITI, IL PRESENTE PRODOTTO VA VENDUTO SOLO DI- ETROPRESCRIZIONE MEDICA Manufactured by: Hergestellt von: Fabricado por: Fabriqué par : Prodotto da: Ohio Medical Corporation | 1111 Lakeside Drive | Gurnee, IL 60031 USA ® 1-847-855-0800 | www.ohiomedical.com 711449 (Rev.3) 02/2016...
  • Page 2 Deutsch Grun Italiano Giallo 711449 (Rev.3) 02/2016...
  • Page 3 MANUFACTURER’S INSTRUCTIONS. IMPROPER USE MAY CAUSE THE DEVICE TO FAIL TO PERFORM AS DESIGNED AND MAY CAUSE INJURY TO THE PATIENT AND/OR HEALTHCARE PROFESSIONAL. The warranties made by Ohio Medical Corporation with respect to these products are voided if the ®...
  • Page 4 Ohio Medical or in accordance with written instructions provided by Ohio Medical, or altered by anyone other than Ohio Medical, or if the product has been subject to abuse, misuse, negligence, or accident.
  • Page 5 If this occurs, immediately turn the unit OFF and contact your nearest Ohio Medical Service 2. The MiniOX 3000 Oxygen Monitor must be calibrated ®...

  • Page 6: Table Of Contents

    MiniOX 3000 Oxygen Monitor Table of Contents ® Section 1 Introduction ..................1-1 General Description ........................1-1 Operating Principles ........................1-2 MiniOX 3000 Oxygen Sensor ....................1-2 ® MiniOX 3000 Instrument ......................1-2 ® Operator Interface ......................1-2 Internal Functions ......................1-2 Data and System Status ....................1-2 Performance Features ........................1-2 Calibration ..........................1-2 Low/High Oxygen Concentration Alarms ................1-3...
  • Page 7 MiniOX 3000 Oxygen Monitor Table of Contents ® High and Low Alarms Test .....................3-6 Installing the Sensor in a Breathing Circuit .................. 3-6 Mounting the Instrument with a Pole Bracket ................3-6 Figure 3-3 Installing Sensor into Tee Adapter ................3-7 Figure 3-4 Sensor In Breathing Circuit ..................3-8 Figure 3-5 MiniOX 3000 Oxygen Monitor with Pole Mounting Bracket ........3-8 ®...
  • Page 8 MiniOX 3000 Oxygen Monitor Table of Contents ® Interferent Gases and Vapors............C-1 Table C-1. Interferent Gases and Vapors................C-1 Appendix D Troubleshooting ................D-1 Table D-1. Troubleshooting....................D-1 Appendix E Error Codes ..................E-1 Table E-1. Error Codes ......................E-1 Appendix F Accessories and Replacement Parts ..........F-1 Table F-1.

  • Page 9: Introduction

    MiniOX 3000 Oxygen Monitor Section 1, Introduction ® Section 1 Audible and visual alarms activate when oxygen concentrations: Introduction • fall below the preset (or default) low alarm The MiniOX 3000 Oxygen Monitor provides ® setting continuous, direct monitoring of oxygen mixtures in a •...

  • Page 10: Operating Principles

    O • if appropriate, activates audible and visual values. alarms The microprocessor also monitors internal systems, The Ohio Medical Corporation oxygen sensor is self- indicating such operating conditions as: zeroing; when no oxygen is present: • calibration required •...

  • Page 11: Low/High Oxygen Concentration Alarms

    MiniOX 3000 Oxygen Monitor Section 1, Introduction ® • each time the monitor is turned ON The operator can silence the audible alarm for three 30-second intervals for a total of 90 seconds; • following sensor disconnection/reconnection • when environmental conditions (presssure, the end of the silence period, the audible alarm humidity and temperature) change reactivates if the alarm conditions is not corrected.

  • Page 12: Error Handling

    MiniOX 3000 Oxygen Monitor Section 1, Introduction ® Test Functions • audible and visual alarms activate, alerting the In addition to alarms that alert the operator to low and operator that recalibration is required. (See expired battery voltage, the MiniOX 3000 Oxygen ®...
  • Page 13 Ohio Medical Corporation Repair at: Remove the sensor from the sealed package and attach it to the coiled cable.

  • Page 14: Setting Up The Miniox ® 3000 Oxygen Monitor

    MiniOX 3000 Oxygen Monitor Section 2, Setting up the MiniOX 3000 Oxygen Monitor ® ® 6. Proceed to Section 3, Operation. (For monitoring in a breathing circuit, CAUTION see Section 3, Installing the Sensor in a Breathing Circuit) Do not handle the sensor unnecessarily 5.

  • Page 15: 3000 Oxygen Monitor

    MiniOX 3000 Oxygen Monitor Section 3, Operation ® Section 3 • if the sensor is disconnected and reconnected to the instrument Operation Recommended practice of calibration is against This section describes the following operational When a more precise measurement is desired, procedures and functions of the MiniOX 3000 ®...

  • Page 16: To Calibrate At 100% O (Figure 3-2)

    MiniOX 3000 Oxygen Monitor Section 3, Operation ® • “CAL” 2. Expose the sensor to 100% oxygen and allow the readings to stabilize prior to initiating the • calibration. • “21% CAL” • 4. Press . The following appears: 3. Press 100%. The following appears on the •...

  • Page 17: Two-Point Linearity Check

    MiniOX 3000 Oxygen Monitor Section 3, Operation ® NOTE: The MiniOX 3000 Oxygen Monitor • If the variation is still greater than ±2%, ® replace the sensor. (See Section 4, Sensor keypad functions. If you do not press Replacement) Setting the Alarms The default Alarm Set points are: •...

  • Page 18: Alarm Conditions

    MiniOX 3000 Oxygen Monitor Section 3, Operation ® • automatically press once after Step 2 • both audible and visual alarms activate to manually proceed to Monitoring Mode 2. To manually terminate the silence mode, press NOTE: The HIGH Alarm value: the down •...
  • Page 19 Thermistor circuit is open on the sen- If alert persists following sensor replacement, sor circuit board call Ohio Medical Corporation service Recalibrate the monitor, ensure proper calibra- tion key pressed for calibration gas of room air Calibration performed using a gas During calibration, “CAL ERR”...

  • Page 20: Test Functions

    ® display Figure 3-5) can be attached to a vertical or horizontal • the audible alarm and visual low alarm activate pole using the Ohio Medical Corporation Mounting • the MiniOX ® 3000 Oxygen Monitor proceeds Bracket (see Appendix F, Accessories/Replacement to the Monitoring Mode, displaying oxygen Parts).
  • Page 21 MiniOX 3000 Oxygen Monitor Section 3, Operation ® SENSOR CABLE RETAINING STRAP SENSOR GASKET DEFLECTOR O-RING 15MM TEE Figure 3-3 Installing Sensor into Tee Adapter 711449 (Rev.3) 02/2016...

  • Page 22: 3000 Oxygen Monitor With Pole Mounting Bracket

    ADAPTER FASTEN RETAINING STRAP TO POSTS ON Figure 3-4 Sensor in Breathing Circuit SLIDE DOVETAIL COMPLETELY INTO BRACKET INSTRUMENT MOUNTING DOVETAIL MOUNTING BRACKET INSTALLED ON POLE Figure 3-5 MiniOX 3000 Oxygen Monitor with Pole Mounting Bracket ® 711449 (Rev.3) 02/2016...

  • Page 23: Maintenance And Care

    3000 Oxygen Monitor requires one ® CAUTION standard 9-volt alkaline battery. To replace the battery: Use only genuine Ohio Medical Corporation 1. Verify that the monitor is turned OFF. The display replacement parts when performing any should be blank. maintenance procedures included in this 2.

  • Page 24: Sensor Replacement

    Tighten the twist collar. is not endorsed by Ohio Medical Corporation. Use 5. Attach the new cable to the instrument. Firmly of other sensor types will void your warranty.

  • Page 25: Sensor And Cable

    The parts process. must be thoroughly dry before they are used. Because of the variability of cleaning, disinfection and sterilization processes, Ohio Medical Corporation can the sterility of an item be ensured. 711449 (Rev.3) 02/2016...
  • Page 26 MiniOX ® Appendix A Alarm LOW/HIGH O System ALARM + 1% of full scale (RTP*) as calibrated in the environment of use Accuracy (total accuracy, including linearity, is 2%) Linearity + 1% of full scale (RTP*) 90% in 20 seconds Nominal Response Time (O directed at sensor at 2 liters per 97% in 30 seconds...

  • Page 27: Electromagnetic Compatibility (Emc) Warning

    MiniOX ® Electromagnetic Compatibility (EMC) WARNING 3000 ® Oxygen Monitor are observed according to the tables below. Misuse may result in failure to perform as designed, including incorrect/erratic readings. Guidance and manufacturer’s declaration - electromagnetic emissions The MiniOX ® user of the MiniOX 3000 should ensure that it is used in such an environment.

  • Page 28: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    MiniOX ® Guidance and manufacturer’s declaration - electromagnetic immunity The MiniOX ® user of the MiniOX 3000 should assure that it is used in such an environment. ® IEC 60601 Compliance Immunity Test Electromagnetic environment - guidance test level Level Portable and mobile RF communications equipment should be used no closer to any part of the MiniOX 3000,...
  • Page 29 MiniOX ® Recommended separation distances between portable and mobile RF communications equipment and the MiniOX ® 3000 The MiniOX 3000 is intended for use in an electromagnetic environment in which radiated RF disturbances ® are controlled. The customer or the user of the MiniOX 3000 can help prevent electromagnetic interference ®...

  • Page 30: Effects Of Pressure, Humidity And Temperature

    MiniOX 3000 Oxygen Monitor Appendix B, Effects of Pressure, Humidity and Temperature ® Effects of Pressure, Humidity and Temperature To ensure accurate and reliable oxygen monitoring, it is necessary to have a thorough understand- CAUTION CAUTION the range of 600 to 900 mmHg (23.62 to 35.43 ing of the effects of pressure, humidity, and inches Hg), as this may cause inaccuracies.
  • Page 31 MiniOX 3000 Oxygen Monitor Appendix C, Interferent Gases and Vapors ® Appendix C Interferent Gases and Vapors Table C-1. Interferent Gases and Vapors INTERFERENT VOLUME % DRY INTERFERENCE EQUIVALENT OF % O Carbon Dioxide 0.1% Cyclopropane 0.2% 7.5% 0.1% Diethyl Ether 0.3% 0.1% Halothane...
  • Page 32 Monitor is turned OFF or Battery is Display is black If monitor does not respond, replace the battery expired. If problem persists, call Ohio Medical Corporation service Press I/O to turn ON monitor No response to keypad Battery is expired...
  • Page 33 Random Access Memory (RAM) error Read Only Memory (ROM) error Analog error Timing error Keypad error* Battery error ** LCD error *Press SET. If error reoccurs, call Ohio Medical Corporation Repair **Replace battery. If error reoccurs, call Ohio Medical Corporation Repair 711449 (Rev.3) 02/2016...
  • Page 34 MiniOX 3000 Oxygen Monitor Appendix F, Accessories and Replacement Parts ® Appendix F Accessories and Replacement Parts Table F-1 Accessories and Replacement Parts ITEM PART NO. Oxygen Sensor 406931 Mounting Bracket, Pole 474664 Mounting Bracket, Wall 10023945 Coiled Cable 472045 Tee Adapter 473021 Retaining Strap...
