WeatherTRAK OptiFlow XR Quick Reference Card

BASIC TASKS
ACTIVATE
Access this controller from WeatherTRAK.net or
WeatherTRAK Mobile
• Call Customer Support at: 800.362.8774
• Fill out the activation form at: hydropoint.com/activate
UNLOCK CONTROLLER
Use "Unlock" feature on WeatherTRAK Mobile or
Press RUN button from controller.
• Use button to go to unlock screen
• Use or button to enter code from
WeatherTRAK.net, or WeatherTRAK Mobile
SET CONTROLLER MODE
Controller On/Off, Shutdown, or Winterized
• Use "Controller Mode" Feature on WeatherTRAK Mobile
SITE CHECK
Manual Operation / Wet Check
• Use "Manual" Feature on WeatherTRAK Mobile
ADJUST
Landscape too wet or too dry
• Use "% Adjust" Feature on WeatherTRAK Mobile
QUICK REFERENCE CARD
ALERT MANAGEMENT
MOBILE APP
Go to the tab on the Controller Settings page.
WEB
Use Alerts Page, or Multi-Controller Alert Report from
weathertrak.net.
CONTROLLER
While at the controller, use the following process:
Press Button. The first screen is the
showing any alert or warning that exists
on your controller. Each two letter code is an Alert
Category. An or appear beneath any category
that has an alert present.
: Flow Alerts — Issue with flow hardware or flow
feature programming. Fix the issue, then press
button to clear alert then retest
Valve Alerts — Issue with valve electrical
:
components or connections. Fix the issue, then
press button to clear alert then retest
Communication Alerts — Reset GPRS Status or
:
call Customer Service for assistance
Water Window Warning — Calculated irrigation
:
schedule exceeds the allowable irrigation time
programmed Water Window
: Water Day Warning — Calculated irrigation
schedule exceeds number of allowable Water Days
programmed in Water Day Mode
: Station High Depletion — Reset Station
Depletion from Manage Page of weathertrak.net or
from Help menu — "Help : 12 — Current Depletion"
Hardware Alert — Issue with controller hardware.
:
Call Customer Service for assistance
Subscription Alert — Call Customer Service to
:
update data service plan
FL1 VC
MV1 VC
TROUBLESHOOTING
If you suspect that there is an issue with your
WeatherTRAK Controller hardware, we have easy to use
LED diagnostic lights on the controller chassis.
Remove the controller panel from its mounted to position
to completely reveal the controller chassis.
Use the chassis diagram above to identify each of the
six LED Diagnostic lights on the chassis and check to
see if each is illuminated. Then, compare result to the
diagnostic table and take appropriate action.
Contact Customer Support with any questions:
800.362.8774 or support@hydropoint.com.
