WICED Smart Quick Start Guide
Note: The content of the ble_trace statements should appear in the console window of the WICED
Smart IDE.
8. To restart the application and view the startup traces of your application, press the Reset button on the
WICED Smart tag (Figure
Instead of using the console window of the IDE, a terminal emulation program, such as Tera Term or Hyperterm,
can be used. Configure the terminal emulation program to use the COM port used by the WICED Smart tag (see
"Verify Driver Installation" on page 12
Note: Verify that the terminal emulation program serial port settings are configured as:
1. Baud Rate: 115200
2. Parity: None
3. Stop bits: 1
4. Flow Control: None.
In addition, the terminal should be set to VT100 terminal and the New Line > Receive parameter
should be set to Auto.
To exit Debug mode and download a new version of the application to the WICED Smart tag:
1. In the WICED Smart IDE, select Trace > Stop Debug Traces (or exit the terminal emulation program used
to monitor debug output traces).
2. Make sure all DIP switches of mini-switch SW4 are set to the ON position.
3. Press the Reset button on the WICED Smart tag (see
Note: Downloading a new application to the WICED Smart tag should work exactly as described in
"Build and Load a Sample Application" on page 13
Broadcom ®
September 24, 2014 • MMPWICED-Smart-QSG203-R
6).
for instructions on identifying the COM port to use).
Viewing Traces from the WICED Smart Tag
Figure 6 on page 19).
and "Run an Application" on page
WICED Smart Development System
17.
