WICED Smart Quick Start Guide
Double-click the newly created heart_rate_monitor-BCM920737TAG_Q32 download target to build the heart
rate monitor application: the IDE console pane (bottom center of the IDE window) displays the build progress.
The build target is appended with the download option, which tells the tool chain to download the firmware when
the build is complete.
Note: If the download option is not automatically appended, users must type it in.
The build output looks similar to the following:
09:51:07 **** Build of configuration Release for project WICED-Smart-SDK ****
"C:\\Users\\bob\\Documents\\WICED\\WICED-Smart-SDK-2.1.1\\WICED-Smart-SDK\\make.exe" heart_rate_monitor-
BCM920736TAG_Q32 download
Linking target ELF
OK, made elf.
..\..\Tools\ARM_GNU\bin\Win32\arm-none-eabi-objdump: section '.data' mentioned in a -j option, but not
found in any input file
Call to heart_rate_monitor_spar_crt_setup @ 002053cd
OK, made C:/Users/bob/Documents/WICED/WICED-Smart-SDK-2.1.1/WICED-Smart-SDK/Wiced-Smart/spar/../../
build/heart_rate_monitor-BCM920736TAG_Q32-rom-ram-Wiced-release/A_20736A1-heart_rate_monitor-rom-ram-
spar.cgs. MD5 sum is:
5e194d7a9560603e5aac69513467a7af *../../build/heart_rate_monitor-BCM920736TAG_Q32-rom-ram-Wiced-release/
A_20736A1-heart_rate_monitor-rom-ram-spar.cgs
--------------------------------------------------------------------------------
Patches start at
Patches end at
Application starts at
Application ends at
Patch size (including reused RAM)
Patch size
Application size
Total RAM footprint
--------------------------------------------------------------------------------
Converting CGS to HEX...
Conversion complete
Creating OTA images...
Conversion complete
OTA image footprint in NV is 5581 bytes
Detecting device...
Device found
Downloading application...
Download complete
Application running
09:51:18 Build Finished (took 11s.939ms)
Broadcom ®
September 24, 2014 • MMPWICED-Smart-QSG203-R
0x00204568 (RAM address)
0x002052D0 (RAM address)
0x00204F70 (RAM address)
0x002053CC (RAM address)
3432 bytes
2568 bytes
1116 bytes
------
3684 bytes (3.6kiB)
Build and Load a Sample Application
