Installation Guide
Single-Control Bath and Shower Trim
K-T8224
K-T8228
M product numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de
M corresponden a México (Ej.
K-12345M)
Français, page "Français-1"
Español, página "Español-1"
1031365-2-B
K-T8226

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K-T8224 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kohler K-T8224

  • Page 1 Installation Guide Single-Control Bath and Shower Trim K-T8224 K-T8226 K-T8228 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 1031365-2-B...
  • Page 2: Important Instructions

    If you do not understand any of the installation or temperature adjustment instructions in this document, in the United States please contact our Customer Service Department at 1-800-4-KOHLER. Outside the U.S., please contact your distributor. IMPORTANT NOTICE TO INSTALLERS! Please fill in the blanks in the information box in the Homeowners Guide and on the valve label.
  • Page 3: Tools And Materials

    To turn the valve off, gently turn it to the ″Off″ position. Shut off the main water supply. Kohler Co. reserves the right to make revisions in the design of products without notice, as specified in the Price Book. Kohler Co.
  • Page 4 Apply a bead of plumbers putty or other sealant around the inlet end of the spout according to the manufacturer’s instructions. Apply thread sealant to the nipple and thread the spout onto the nipple. Carefully tighten with a clean strap wrench. Remove all excess putty. 1031365-2-B Kohler Co.
  • Page 5 Carefully tighten with a clean strap wrench. Press the escutcheon against the finished wall and secure with the setscrew. Remove all excess putty. Flush out the system. Apply thread sealant tape to the shower arm and thread the showerhead to the shower arm. Kohler Co. 1031365-2-B...
  • Page 6: Water Temperature Adjustment

    Reinstall the collar on the valve stem with the setscrew against the side of the tab. Reinstall the O-ring, rotate the valve stem counterclockwise to shut the water off. Recheck the water temperature. Complete the information on the valve label (if supplied). 1031365-2-B Kohler Co.
  • Page 7 Position the handle over the handle stem eyelets. Secure by threading the plug into the handle. Press the plug button firmly into place. If needed, install the second O-ring, ring, and end piece. Swirl and Square Handle Kohler Co. 1031365-2-B...
  • Page 8: Complete The Installation

    Remove the aerator assembly from the spout by turning it counterclockwise. Turn on the main water supply. Turn the valve to the center and run water for approximately one minute to flush the system. Check all connections for leaks. Reinstall the aerator. 1031365-2-B Kohler Co.
  • Page 9: Guide D'installation

    S’il ne vous est pas possible de comprendre les instructions d’installation ou de réglage de la température données par ce document, veuillez contacter notre département du service clientèle aux États-Unis.1-800-4-KOHLER. Hors des États-Unis, veuillez contacter votre distributeur. Kohler Co. Français-1...
  • Page 10: Outils Et Matériels

    Pour fermer la poignée, la tourner doucement sur la position ″Off″. Couper l’alimentation d’eau principale. Kohler Co. se réserve le droit d’apporter toutes modifications sur le design des produits et ceci sans préavis, tel que spécifié dans le catalogue des prix.
  • Page 11 Appliquer un ruban d’étanchéité sur le filetage du mamelon et visser le bec sur ce dernier. Serrer doucement à l’aide d’une clé à sangle propre. Retirer tout excédant de mastic. Kohler Co. Français-3 1031365-2-B...
  • Page 12 Presser l’applique contre le mur fini et sécuriser avec la vis de retenue. Retirer tout excédant de mastic. Vidanger les conduites. Appliquer un ruban d’étanchéité sur le bras de douche et visser la pomme de douche sur ce dernier. 1031365-2-B Français-4 Kohler Co.
  • Page 13 Réinstaller le joint torique, tourner la tige de la valve vers la gauche pour arrêter l’eau. Vérifier de nouveau la température de l’eau. Compléter l’information sur l’étiquette de la valve (si fournie). Kohler Co. Français-5 1031365-2-B...
  • Page 14 Positionner la poignée sur les oeillets de la tige de la poignée. Sécuriser en vissant le bouchon sur la poignée. Presser le bouchon en place pour le mettre en place. Si besoin, installer le second joint torique, la bague, et la pièce de raccordement. 1031365-2-B Français-6 Kohler Co.
  • Page 15: Compléter L'installation

    Tourner l’ensemble de l’aérateur du bec vers la gauche pour le retirer. Ouvrir l’alimentation d’eau principale. Tourner la valve vers le centre et faire couler l’eau pendant une minute environ pour purger le système. Vérifier s’il y a des fuites dans les connexions. Réinstaller l’aérateur. Kohler Co. Français-7 1031365-2-B...
  • Page 16: Guía De Instalación

    Si usted no entiende las instrucciones de instalación o de ajuste de temperatura contenidas en este documento, desde los Estados Unidos llame a nuestro Departamento de Atención al Cliente, al 1-800-4-KOHLER. Fuera de los Estados Unidos, comuníquese con su distribuidor. Kohler Co.
  • Page 17: Herramientas Y Materiales

    Gracias por elegir los productos de Kohler Le agradecemos que haya elegido la calidad de Kohler. Dedique unos minutos para leer este manual antes de comenzar la instalación. En caso de problemas de instalación o de funcionamiento, no dude en contactarnos.
  • Page 18 Antes de comenzar (cont.) La empresa Kohler se reserva el derecho de modificar el diseño de los productos sin previo aviso, tal como se especifica en la lista de precios. 1031365-2-B Español-3 Kohler Co.
  • Page 19 Aplique sellador de roscas en el niple y enrosque el surtidor en el niple. Apriete cuidadosamente con una llave de correa limpia. Limpie el exceso de masilla de plomería. Kohler Co. Español-4 1031365-2-B...
  • Page 20 fijación. Limpie el exceso de masilla de plomería. Haga circular agua por el sistema. Aplique cinta selladora de roscas en el brazo de ducha, y enrosque la cabeza de ducha en el brazo de ducha. 1031365-2-B Español-5 Kohler Co.
  • Page 21 Vuelva a instalar el empaque de anillo (O-ring) y gire la espiga a la izquierda para cerrar el suministro de agua. Vuelva a verificar la temperatura del agua. Escriba la información en la etiqueta de la válvula (si se ha suministrado). Kohler Co. Español-6 1031365-2-B...
  • Page 22 Coloque la manija sobre los ojales de la espiga de la manija. Fije enroscando el tapón en la manija. Presione el tapón en su lugar. De ser necesario, instale el segundo empaque de anillo (O-ring), anillo y pieza terminal. 1031365-2-B Español-7 Kohler Co.
  • Page 23 Abra el suministro principal de agua. Gire la válvula al centro y deje correr el agua durante aproximadamente un minuto para limpiar el sistema. Revise que no haya fugas en las conexiones. Reinstale el aireador. Kohler Co. Español-8 1031365-2-B...
  • Page 24 USA: 1-800-4-KOHLER Canada: 1-800-964-5590 México: 001-877-680-1310 kohler.com ©2005 Kohler Co. 1031365-2-B...
