Tyco Fire Product CENTRAL H-1 Instruction Manual

Model H-1
Adjustable
Dry Sidewall
Automatic Sprinkler
Manufactured by: Central Sprinkler Company
451 North Cannon Avenue, Lansdale, Pennsylvania 19446
Product
Description
The Model H-1 Dry Horizontal
Sidewall Sprinklers allow the
Installation of sprinklers in areas
subject to freezing while being supplied
from a wet pipe sprinkler system. The
adjustable version uses a special cast
iron fitting. The primary advantage of
the adjustable version is the 2
mm) of field adjustment. This is
provided by the unique feature of a
special elbow that allows more
adjustment than ever before. This
ensures perfect fit to the wall as the
sprinkler can easily be adjusted after
the outside face of the wall is installed.
Because the H-1 Dry Horizontal
Sidewall is allowed with NFPA 13
spacings for sidewall sprinklers in
either light or ordinary hazard, it can
throw considerably further than the
alternative method suggested in NFPA
13 of a dry pendent sprinkler on a 45°
angle.
The escutcheon assembly is com-
prised of a support piece permanently
attached to the sprinkler frame. The
wall escutcheon plate has 1 ⁄
of field adjustment and can be installed
after the sprinkler.
Therefore, the total field adjustment
for the Model H-1 Adjustable Dry
Sidewall Sprinkler is 2 3 ⁄ " (69.9 mm).
4
The Model H-1 is Listed by U.L. and
U.L.C. for use as a standard sprinkler
that qualifies for installation in accor-
dance with current NFPA 13 Standards.
Operation: A fusible alloy is sealed
into a bronze center strut by a stainless
steel ball. When the alloy melts at its
rated temperature, the ball is forced
H-1 Dry Sidewall
upward into the center strut
releasing the two ejectors and
operating the sprinkler.
Model: H-1
Style: Dry Sidewall (adjustable or
" (63.5
1 ⁄
2 Wrench: H-1 (Part #1090) For adjust-
ment of sprinkler only. See
Installation Sequence Steps #2
and #4 on page 3.
Orifice Size:
K-Factor: See "Ordering Range Chart"
on page two.
Thread Size: 1" (25 mm) NPT
Temperature Rating & Frame Arm Color:
135°F/57°C: (*lead only)
165°F/74°C: (*wax, lead, wax-over-lead)
212°F/100°C: (*wax, lead, wax-over-lead)
286°F/141°C: (*wax, lead, wax-over-
lead, Listed as high temperature, wax
coated for installation where maximum
ambient ceiling temperature does not
exceed 150 ° F.)
* Wax, lead and wax-over-lead are
U.L. Listed only.
" (6.4 mm)
Approvals:
4
Maximum Working Pressure: 175 psi
Factory Hydro Test: 100% at 500 psi
Standard Finishes: brass, chrome plated
Escutcheon: brass, chrome plated and
Highest Allowable Ambient Storage
Temperature: 100°F/38°C
Technical
Data
non-adjustable)
1
⁄ " (15 mm)
2
U.L., U.L.C.
M.E.A. (375-75-SA)
(12.1 bar)
(34.5 bar)
white painted with
additional special finishes
available upon request
1-98
1 "
⁄
Orifice
(15 mm)
2
Dry Sidewall
Automatic
Sprinklers
No. 5-4.0
