Techly I-TOOL-SD-241TY User Manual

User's Manual
EN
Manuale d'istruzione
IT

FEATURES:

EN
• The multi-purpose tool offers an excellent all-round solution,
ideal for working on small PCBs, components, soldering etc.
• The magnifying lamp with integrated 3rd hand is intended
for illuminating work areas and it is equipped with
a magnifying glass.
• The tool also comes with soldering iron stand, alligator clips,
soldering wire spool holder, sponge, as well as cleaning ball
to help with soldering.
• It can be powered either by 4 AA batteries(not included)
or an external power adaptor(5.9V 0.5A).

SPECIFICATIONS:

• Magnifying glass lens size: 90 mm
• Magnification: 3X
• LED illumination: 16 pieces LEDs
• Neck (for magnifying glass) length: 265 mm
• Neck (for alligator clips) length: 250 mm
• Sponge size: 30 x 50 mm
• Base size: 190 x 170 mm

OPERATING INSTRUCTION:

• Take the lamp out of the packaging and place it on a level,
even surface.
• Adjust the lamp holder and the light-arm as desired.
• Insert 4 AA Batteries or use the power adaptor to get
it powered up.
• Switch on the LED magnifying lamp, then start your operation.

Notes:

1. Please note the 2 iron sticks are used to hold the soldering wire
spool. Before use, please unscrew the 2 screws put the 2 iron
sticks vertically, then fix the screws back tight.
LENTE DI INGRANDIMENTO
Please unscrew
the 2 screws first
2. Open the battery cover on the back side, put 4×1.5V AA
batteries(not included) inside, then put the cover back.

ATTENTION!

• The product can only be used indoors, never outdoors.
Do not expose to moisture under any circumstances.
• The product is not a toy and should be kept out of children's
reach.
• Do not look directly into the light source when the lamp
is in operation.
• Never look into light sources, such as LED lamps or lasers,
through the magnifying glass. This may result in eye injuries,
due to the optical interaction.
• Never leave the lamp without supervision when it is in use.
• Check the lamp for damage from time to time.
Don't touch the device if the lamp or the mains adaptors show
any signs of damage. Please switch off the appropriate mains
socket and then carefully pull the mains plug from the socket
then take it to a specialist workshop.

MAINTENANCE:

• Remove loose particles with clean compressed air and then brush
off remaining residues with a soft fine brush.
• Clean the surface with a lens cleaning cloth or a clean, soft and
lint-free cloth. To remove fingerprints and other fat residues,
the cloth can be moistened with water or lens cleaning solution.
• Do not use acid, alcohol or other solvents or rough, fuzzy cloths.
Avoid excessive cleaning and extorting too much pressure.
• Never touch the lens with your fingernails or other sharp objects.
• Dispose of your used batteries/rechargeable batteries
free of charge at your local collection point, our stores or
anywhere where batteries/rechargeable batteries are sold.
