Utilizing Environmentally Safe, CFC-free R-134a Refrigerant
DL27-8

Models Available

•DL27-8
•DL48-8
•DL48-10
•DL48-12
•DL60-8

REFRIGERATION SYSTEM

The self-contained refrigeration system is rear
mounted, concealed behind a removable louvered
cover. Full-length front air grille allows for even air
circulation to condensing unit.
Rated", air-cooled, hermetically sealed, capillary
type refrigeration system is installed in each model.
Plasticized finned coil and air circulating fans are
contained within an easily accessible rear mounted
housing. Our unique airflow design allows the cab-
inet to be enclosed on both sides or to be mounted
flush against a wall. Our refrigeration system, fully
charged with R-134a refrigerant, is designed to
maintain 38° - 40° Fahrenheit while operating with
an unrestricted air supply in an ambient tempera-
ture of 100° Fahrenheit. All condensate water is
directed to a non-electric condensate vaporizer
located in the compressor compartment, thus no
plumbing is required. A strict quality assurance
team inspects all materials and components to cer-
tify that each model conforms to the most exacting
standards. All models are performance tested for
a minimum of 16 hours prior to crating.
REFRIGERATORS
DL72-18
•DL60-12
•DL60-16
•DL72-12
•DL72-18

CABINET CONSTRUCTION

All materials are of top quality and are assembled
under rigid supervision conforming to strict quality
assurance requirements.
A "Performance
welded construction and is internally supported
and braced for rigid unit construction. Exterior cab-
inet back and bottom are heavy gauge galvanized
steel. Worktop is constructed of heavy gauge pol-
ished stainless steel for durability.
Cabinet design eliminates overlapping panels with
raw edges. Interior corners are rounded with a
radius for cleaning ease. All cabinet joints and
seams are vapor-tight sealed. An easily removable
anti-sweat door heater, concealed by a non-metal-
lic, non-conductive, high impact thermal breaker
strip, eliminates condensation build-up on case
front.

INSULATION

All cabinet walls, top, and bottom have high den-
sity, foamed-in-place, non-CFC polyurethane insu-
lation.
SANDWICH UNIT
REFRIGERATORS

Standard Features

• Unique Air Flow Distribution Allows Pan Product to
Maintain 33
–41
F Being in Compliance with and Certified
0
0
Under the New '98 NSF Standard For Preparation Units.
• Modern, State-of-the-Art Styling Performance Rated
Refrigeration System Utilizing Environmentally Safe R-134a
Refrigerant
• Easily Serviceable Back Mounted Compressor
• 2" Non-CFC Polyurethane Foam Insulation
• Spring Loaded, Self Closing Field Rehingeable Doors
• Magnetic Snap-In Gasket
• Adjustable 6" Legs
• Heavy-Duty, Epoxy-Coated Steel Shelves
• Interior Hanging Thermometer
• 12" Deep Full Length Nylon Cutting Board
• Cabinet Construction Consisting of Stainless Steel Exterior
& Interior
• Non-Corrosive, Plasticized Fin Evaporator Coil
• Completely Enclosed, Vented and Removable Case Back
• Automatic, Energy Saving, Non-Electric Condensate
Disposal
• 1/6 Size Pans, 4" Deep
• 10 ft Cord and Plug Attached
Optional Features & Accessories
•Remote Models - R
•Electric Condensate
•Additional Shelves
•Pan Opening Sizes

SHELVING

Shelves are designed for heavy-duty use with
.306" diameter frame and brace members and
Case is of all metal
.140" diameter fill wires spaced
are welded steel and epoxy-coated for a durable,
long, rust-free service life.

DOOR CONSTRUCTION

Door shells are constructed of heavy-gauge stain-
less steel and are internally braced and urethane-
foam-insulated for rigidity.
/
"
welded construction and polished. Replaceable
1
4
snap-in door gaskets are self adjusting, heavy-
duty, magnetic type. Door handles and hinges are
chrome-plated and non-corrosive.
spring loaded, heavy duty, self-closing.
•Door Locks
•Single Overshelf
•Double Overshelf
/
" apart. Shelves
3
4
Door corners are of
Hinges are
