Continental Refrigerator DL1RF-SS Specifications

REFRIGERATOR/FREEZER
Utilizing Environmentally Safe, CFC-free R-134a/ R-404a Refrigerant
DL1RF-SS

Models Available

• Remote
• Consult Factory
Refrigeration System
Two"performance rated", air cooled, hermetically
sealed, capillary-type refrigeration systems are
installed on the top of each dual temp. Plasticized fin
coil and air circulating fans are contained within an eas-
ily accessible, low-profile, interior ceiling mounted
housing. Both refrigeration systems are fully charged
with refrigerant and evenly matched providing equal air
distribution. Refrigerator sections are designed to main-
tain 38-40 degrees Fahrenheit (3 to 5 degrees
Centigrade), and Freezer sections 0 degrees
Fahrenheit (-18 degrees Centigrade) while operating
with an unrestricted air supply in a maximum ambient
temperature of 100 degrees Fahrenheit. Freezer sys-
tems have an automatic electric defrost timer which ini-
tiates defrost cycles at pre-determined intervals. All
condensate water is directed to the cabinet bottom for
connection to an automatic thermostatically controlled
evaporator which is supplied with each model. A strict
quality-assurance team inspects all materials and com-
ponents to certify that each model conforms to the most
exacting standards. All models are factory perform-
ance tested for a minimum of 16 hours prior to crating.
DL1RFE-SS
OTHER MODELS
• Hinged Glass Door
Cabinet Construction
All materials are of top quality, assembled to conform
with strict quality-assurance requirements. The cabinet
front and doors are constructed of heavy-gauge pol-
ished stainless steel for durability. All cabinet joints and
seams are sealed vapor tight. Case is of all metal, weld-
ed construction and internally supported and braced for
a rigid unit construction. Cabinet design eliminates
overlapping panels with raw edges. Cabinet body, and
doors are insulated with non-CFC, foamed-in-place
polyurethane foam with an average thickness of 3 inch-
es to ensure increased energy efficiency. Full length
louvered air grille located above the doors allows equal
air circulation to the condensing units. Easily remov-
able, low wattage, anti-sweat door heaters concealed
by a non-metallic, non-conductive, high-impact thermal
breaker strip eliminate condensate build up on the cab-
inet front. Automatic interior lighting is controlled by
door openings. Cabinets are equipped with 6-inch
adjustable stainless steel legs.
REFRIGERATOR/FREEZER
• Modern, State-of-the-Art Styling
• Performance Rated Refrigeration Systems
• 3" Non-CFC Polyurethane Foam Insulation
• Chrome Plated Flow Line Handles
• Cam-Action Lift-Off Hinges
• Self-Closing Doors
• Magnetic Snap-In Door Gaskets
• Cylinder Lock In Each Door
• Automatic Electric Condensate Evaporator
• Adjustable 6" Stainless Steel Legs
• Heavy-Duty, Epoxy-Coated Steel Shelves
• External Digital Thermometers
• Automatic Electric Defrost On Freezer Systems
• Automatic Interior Lighting
Standard (S/S Front, Aluminum Ends & Interior)
AVAILABLE
Suffix SA (S/S Exterior, Aluminum Interior)
• DL1RFX-SS
Suffix SS (S/S Exterior & Interior)
OVER/UNDER
DUAL TEMP

Standard Features

Shelving
Shelves are designed for heavy-duty use with .306"
diameter frame and brace members and .140" diameter
fill wires spaced 3/4" apart. Shelves are welded steel
and epoxy-coated for a durable, long, rust-free service
life. Adjustments are in 1/2 inch increments and a wide
door opening allows the use of a variety of optional pan
and tray slide types.
Door Construction
Door shells are constructed of heavy-gauge stainless
steel and are internally braced and urethane-foam-
insulated for rigidity. Door corners are of welded con-
struction and polished. Replaceable snap-in door gas-
kets are self-adjusting, heavy-duty, magnetic type. Door
handles and hinges are chrome-plated and non-corro-
sive. Doors are provided with built-in cylinder locks
which are keyed alike. Hinges are cam
type featuring positive safety stop at 120
degrees.
- action, lift-off
