Xylem JABSCO 18660 Series Quick Start Manual

SELF-PRIMING PUMP
FEATURES
Motor: Permanent magnet type, fully
enclosed, stainless steel shaft.
Dimensions:
3" (76mm) high, 6-3/8" (162mm)
long, 4-3/4" (120mm) wide
Weight:
4-1/2 lb (2 kg) (approx.)
Body:
Bronze
Impeller: Jabsco Neoprene compound
Seal:
Lip type
Ports: 1/2" Internal Pipe Threads
1" External Hose Barb
Adapter for 3/4" External Garden
Hose Thread included
Motor meets USCG Electrical Standards 183.410 and
ISO 8846 MARINE for IGNITION PROTECTION on
gasoline powered vessels.
WARNING
!
Explosion hazard. Do not pump
gasoline, solvents, thinners or other
flammable liquids. T o do so can cause
an explosion resulting in injury or death.
APPLICATION
Use for bilge pumping, livewell circulation, washdown
and general pumping requirements. If bilge water
contains significant amount of oil, the standard impeller
should be replaced with impeller No. 6303-0003, which is
an oil-resistant nitrile material.
Pump has a dry prime suction lift of about 4 feet (1.2m)
and a lift to 20 feet (6m) when primed. BE SURE
SUCTION LINES ARE AIRTIGHT.
Model 18660-0121
OPERATION
Flexible impeller pumps must NOT be run dry, as the
pumped liquid is the lubricant for the impeller. Observe
the outlet and shut off pump as soon as liquid stops
flowing. An automatic level switch is convenient to
control the pump.
The pump cannot run against a closed outlet such as
encountered when using a garden hose type shut-off
nozzle.
Pressure for normal operation should not exceed 20 feet
of head (8.7 psi).
Temperature of pumped liquid may be in the range of
45° - 180°F (7° - 82°C).
WARNING
!
Light housing gets hot during
Motor runs hot—about 180° is a normal
operation. Do not touch during
temperature. Prolonged contact during
or immediately after operation.
operation may cause a burn.
Burns can result.
