Xylem Jabsco 18620-0003 Quick Start Manual

REVERSIBLE PUMP
FEATURES
Bronze
Nitrile
Body:
Lip Type
Impeller:
Reversible Permanent Magnet Type with
Seal:
Integral Reversing Switch and Fuse
Motor:
3/4" Garden Hose External
3-3/8" (85mm)
Ports:
8-5/8" (172mm)
Height:
4" (95mm)
Length:
5-1/2 lb (2.5 kg) Approx.
Width:
Weight:
WARNING
Explosion hazard. Do not pump gasoline, solvents,
!
thinners or other flammable liquids. To do so can
cause an explosion resulting in injury or death.
Explosion hazard. Do not operate with rivets
WARNING
!
removed from motor case. Explosion resulting in
personal injury, death or property damage can
occur. Case openings must be sealed to avoid
explosion and maintain ignition protected rating.
APPLICATION
Use for circulating and draining bait tank, engine oil
changing or general pumping requirements. With a wet
impeller, pump will produce a suction lift of about 3 to 4
feet (0.9 to 1.2m) and a lift of about 10 feet (3m) when
primed. BE SURE SUCTION LINES ARE AIRTIGHT.
INSTALLATION
The pump must be mounted in a dry location - the
motor is not waterproof and must not be submerged.
SELECTION OF A COOL, VENTILATED location will
generally extend pump motor life. The unit can be
mounted in any desired position. It is best to mount so
that water dripping from loose port connection will not
wet the motor. The pump head may be mounted at
90 degree increments on the motor to accommodate
plumbing connections as needed.
PLUMBING CONNECTIONS
Pumps have external hose threads and internal 3/8" pipe
threads. Use hose that does not kink when bent or
collapse due to the suction of the pump. Arrange hoses
to trap liquid in pump body to wet the impeller. Wetting
the impeller aids in priming and extends impeller life. All
hoses must have airtight connections.
HEAD VS. FLOW TABLE
Total Head
PSI Feet
2.1 5
4.3 10
8.7 20
17.4 40
Table shows approximate Head-Flow for new pump.
MODEL 18620-0003
Capacity
Metres GPM LPM
1.5 1.8
3.0 1.7
6.1 1.6
12.2 1.2
6.8
6.4
6.1
4.5
