Veridian Healthcare JXB-311 Quick Start Manual

Non-Contact
Infrared Thermometer
Model JXB-311 / Ref No 09-313
These brief instructions allow you to quickly begin using your Infrared
Thermometer for Body Temperature Measurements. Please refer to the
Instruction Manual for more detailed instructions covering all features of the
thermometer, including Object/Surface and Room Temperature measurements.
• The infrared technology used in this thermometer is safe
and is not harmful in any way. However, we recommend
avoiding looking into the lens during use.
The Infrared Thermometer offers a selection of settings for
for person, object/surface and room measurements.
To toggle between modes:
1. Press and release the POWER / SCAN button to turn
the thermometer on. The unit will run a self-test and all
symbols on the display will momentarily appear.
2. Press and release the MODE button to scroll through and
select person, object/surface and room temperatures.
IF YOU HAVE ANY QUESTIONS OR ARE EXPERIENCING DIFFICULTIES,
PLEASE CALL THE TOLL-FREE CUSTOMER SERVICE HELP LINE FOR FURTHER
Self-test
Person Mode
ASSISTANCE AT 1-866-326-1313.
To measure body temperature using your Infrared Thermometer,
follow these steps:
1. Press and release the POWER / SCAN button to turn the
thermometer on. The unit will run a self-test and all symbols
on the display will momentarily appear, Fig. 1.
2. The display will show dashed lines, the selected mode, and
the temperature mode (°F/°C). The thermometer is ready for
measurement, Fig. 2.
3. Press and release the POWER / SCAN button while aiming
the infrared lens at the individual's forehead, holding the
thermometer approximately 0.5" – 1.0" away.
4. When the thermometer is in the correct position, it will slightly
vibrate, indicating the positioning sensor has detected the
ideal reading location and the measurement has been taken.
5. The results will be displayed, Fig. 3.
6. If the results are at or above 100.4°F (38°C), the device will
vibrate 3 times, indicating a fever may be present.
7. After approximately 30-seconds of non-use, the thermometer
will automatically shut off.
Fig. 1
Fig. 2
Fig. 3
