8 Parts overview and scope of delivery

A
21
20
19
18
17
16
15
14
13
Illustration 1: All parts of the microscope
1 LCD display (movable)
3 Function light (display)
5 Coarse focus
7 Fine focus
9 On/Off switch
11 Function lights (incident light brightness)
13 Translucent lighting
15 Object clamps
17 "Tra" button (translucent lighting)
19 Objective
21 Microscope head
23 USB A connector
25 DC barrel connector
*not included
1
11
12
2
3
4
5
6
7
8
B
9
10
C
24
25
2 Memory card slot (MicroSD card*)
4 USB-A port (mouse*)
6 Friction adjustment
8 Incident lighting
10 DC connection socket (power)
12 Function lights (transmitted light brightness)
14 Object plate, exchangeable
16 Function light (voltage)
18 "Inc" button (incident lighting)
20 Zoom ring
22 Mouse
24 Mains plug
26 Hook wrench
14
23
22
F
26
D
E
7 / 20
