1
Aprire la ganascia a morsa premendo le estremità delle leve
delle semiganasce. Posizionare la ganascia a morsa aperta
sul profilo toroidale del raccordo pressfitting (vedere
figura A, copertina posteriore).
2
Assicurarsi che la ganascia a morsa sia posizionata
correttamente sul profilo toroidale del raccordo pressfitting
(vedere figura B, copertina posteriore).
3
Rilasciare entrambe le leve delle semiganasce.
4
Pressare il pressfitting conformemente alle istruzioni di
funzionamento della pressatrice.
5
Assicurarsi che al termine della pressatura la ganascia a
morsa sia completamente chiusa (vedere figura C,
copertina posteriore).
6
Sganciare la ganascia a morsa dal pressfitting (vedere
figura D, copertina posteriore).
B262-006 © 01-2014
964.876.00.0 (05)
IT
41
