SERVICE MANUAL
(For Europe Use)
CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section
on page 2 of this manual.
DVD and CD
PLAYER
SPECIFICATIONS
DVD VIDEO PLAYER
Signal system
Laser
Frequency response
Signal/Noise ratio
Audio distortion+noise
Channel separation
Dynamic range
OUTPUTS
Video outputs
S-video outputs
Audio outputs (digital audio)
Audio outputs (analog audio)
GENERAL
Power supply
Power consumption
Dimensions
Weight
DV-3000 DVD Player
STANDBY/ON
POWER
PHONES
MIN
MAX
PAL/AUTO/NTSC
Wavelength 650nm
20Hz to 20kHz
85dB
-80dB(1kHz)
90dB(1kHz)
85dB(1kHz)
1.0V(p-p), 75ohm, negative sync.
(Y)1.0V(p-p), (C)0.286V(p-p)
75ohm, negative sync.
0.5V(p-p), 75ohm
2.0Vrams(1KHz,0.8dB), 10Kohm
AC120V, 60Hz
20W
435 x 95 x 280 (mm)
Around 4kgs
DVD/VCD/CD
REMOTE
SENSOR
CONTENTS
SERVICE PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . 2-3
LOCATION OF CONTROLS . . . . . . . . . . . . . . . . . . . . . . 4-6
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 7
ELECTRICAL TROUBLE SHOOTING GUIDE . .. . . . . . 8-18
PRINTED CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-25
EXPLODED VIEW/PARTS LIST(CABINET) . . . . .. . . . . . 26
REPLACEMENT PARTS LIST . . . . . . . . . . . . . . . .. . . 27-28
MODEL
DV-3000
OPEN/CLOSE
STOP
PLAY
PAUSE/STEP
PREVIOUS
NEXT
SEARCH
CD-R/CD-RW COMPATIBLE
Advertisement
Related Manuals for Teac DV-3000
Summary of Contents for Teac DV-3000
- Page 1 MODEL SERVICE MANUAL DV-3000 (For Europe Use) CAUTION : Before servicing this chassis, read the "PRODUCT SAFETY SERVICE FOR VIDEO PRODUCTS" section on page 2 of this manual. DVD/VCD/CD DV-3000 DVD Player OPEN/CLOSE STOP PLAY PAUSE/STEP PREVIOUS NEXT STANDBY/ON POWER...
- Page 2 PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS CAUTION: DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN ANY WA Y AND SUBJECT: X-RADIATION N E V E R P E R F O R M C U S T O M I Z E D I N S T A L L AT I O N S W I T H O U T 1.
- Page 3 SERVICING PRECAUTIONS CAUTION : Before servicing the DVD covered by this Electrostatically Sensitive (ES) Devices service data and its supplements and ADDENDUMS, read Some semiconductor (solid state) devices can be damaged and follow the SAFETY PRECAUTIONS NOTE : if easily by static electricity. Such components commonly are unforeseen circumstances create conflict between the called Electrostatically Sensitive (ES) Devices.
- Page 4 PREPARATIONS BEFORE OPERATION FRONT PANEL DVD/VCD/CD DV-3000 DVD Player OPEN/CLOSE STOP PLAY PAUSE/STEP PREVIOUS NEXT STANDBY/ON POWER SEARCH PHONES REMOTE SENSOR CD-R/CD-RW COMPA TIBLE 1. POWER 8. PREVIOUS/NEXT 2. STANDBY INDICATOR 9. SEARCH 3. DISC TRAY 10. REMOTE SENSOR 4. OPEN/CLOSE 11.
- Page 5 DISPLAY Chapter/track Dolby Digital Pause indicator Title indicator Program indicator Track calender indicator indicator VCD and CD Repeat play indicator Remain indicator Lock indicator Angel indicator Play indicator indicator indicator TITLE CHP/TRK PROGRAM REPEAT REMAIN DIGITAL 1/2 2/3 D1 RESUME Minute Second indicator Disc recording...
- Page 6 NAMES AND LAYOUT OF REMOTE CONTROLS 1. OSD 2. DIMMER 3. NUMBER BUTTONS 4. SEARCH 5. SET UP 6. TITLE 7. PLAY 8. PREVIOUS/NEXT POWER DIMMER ANGLE STANDBY 9. STOP PLAY MODE 10. DIRECTIONS DIGEST 11. TV SYSTEM TIME SEARCH LANGUAGE 10/0 REMAIN...
- Page 8 Electrical Trouble Shooting Guide Connection of the unit is correct. Setting of the unit is correct Is power normal? Refer to power guide. Is fluoresce display correct? Refer to display guide Is open/close normal? Refer to open/close guide Can disc be read? Refer to read disc guide Is video normal?
- Page 9 Power Circuit abnormal START F301 is open. XP301 is open. XP302 is open. Is C328 AC 220V? Power cord isn't inserted firmly or power cord is open. Check commute circuit. Is C301 DC 310V? Check L301 and L302. Are 2,3 pin of N301 resistance Replace N301.
- Page 10 Display abnormal START Check if voltage of screen F1 and F2 is 3.3V. Check if voltage of 34 pin of UPD16311 is -24V. Does the screen Check grounded negative voltage of screen F1 and F2. appear? Replace UPD16311. Check if connection cord between screen and main board is broken? Is display normal? Check if UPD16311 pin is connected.
- Page 11 Open/close abnormal The door isn't open. Is "OPEN" showed on the screen? Is there voltage difference Check if RMC pin of in XP102UNLOAD pin and XS107 has a waveform. LOAD pin? Does XS107 power have voltage? Does drive motor have voltage? Replace key-circuit board.
- Page 12 Read disc abnormal DISC IN Refer to focus guide. Focus on? Refer to laser guide Is laser normal? Refer to focus guide Does the disc turn? Refer to TOC guide Can TOC be read? Normal...
- Page 13 Video abnormal Check connection between Is voltage of XS109 normal? video encoder and XS109. No picture, no sound. Replace main board. Check jack of output board No picture, have sound. or replace main board. Have picture, no color or color Check main board and replace disappeared during playback .
- Page 14 Audio abnormal Have picture, no sound Check connection between R, L pin of XP202 Check if voltage of R, L pin and PCM1723 of XP202 is normal Is N202 and N203 signal Check 4558 and surrounding components output? Is transistor V208 and Replace transistor V209 for mute usage broken down?
- Page 15 Focus abnormal No focus 1. Check connection cord. Does normal voltage at FCS+ 2. Replace pickup. and FCS- of XS100? 1. Check connection between 14, 7 pin of BA5945 and FCS+, FCS- of XS100. Does normal voltage at 2. Check if G101, G102 normal operation. D104 pin 14, 7? 3.
- Page 16 Laser abnormal No laser 1. Check connection between pickup Is LD pin of XS100(18, 30) and main board. 4.5V? 2. Replace pickup. 1. Check connection between D1890 of pin LD and XS100. Does voltage at D103 2. Check D1890 and peripheral pin of 52, 81? components.
- Page 17 Turn abnormal Disc doesn't turn. Check if voltage of SP+ and Check connection of mechanism. SP- of XS103 are different. 1. Check connections between BA5954 and XS103. Check if voltage of 11 and 2. Check BA5954 and peripheral 12 pin of D104 are different. components.
- Page 18 TOC abnormal TOC doesn't read. 1. Refer to laser guide. Limited switch is closed. 2. Check slide motor and connections Is laser on? to main board. Is FOK normal? 1. Check connection between 39 pin of D1890 and 7 pin of XS100. Does normal RFsignal at 2.
- Page 19 V501 VFD25-0705 S513 RESUME TIME.S DIGEST VD512 IN4148 POWER KEY- KEYO KEY+ A.MODE VD511 R505 R502 IN4148 C504 C503 R508 R509 R507 100U/6.3V 0.1U OPEN5 OPEN3 OPEN2 OPEN4 VD510 IN4148 DISC4 DISC5 EXCHANGE OPEN1 XP501 VD509 U547 IN4148 DOUT DATA DISC1 DISC2 DISC3...
- Page 20 D3000P EARPHONE CIRCUIT...
- Page 21 AD21 POWER CIRCUIT...
- Page 22 SCART-868-312P OUTPUT CIRCUIT...
- Page 23 DVD3100K KEYBOARD DSM6012BM MAIN BOARD...
- Page 24 AD21POWER BOARD SCART-868-312P OUTPUT BOARD D3000P BOARD D3100PC BOARD...
- Page 25 TEAC DV-3000 PARTS No. PARTS NAME b6032U DOOR b6038 TRANSPARENT WINDOW b6036H KNOB b6031U FRONT PANEL a2793 SCREW M3 6 SEARCH SWITCH UNIT b6035H FUNCTION BUTTON b6033 FOOT D b1633 FOOT SPACER A b1632 FOOT SPACER a2766 SCREW ST3 12...
- Page 26 A2773 37 9A08763600 KEY UNIT 0813 38 9A08619900 SCREW,M3X8 A2794 39 9A08765000 POWER BUTTON UNIT 0815 40 9A08767820 PHONE UNIT S7019 41 ‑‑‑‑‑‑‑‑‑‑ TEAC CHARACTER 42 9A08794500 POWER BUTTON B6034H 43 9A08794600 ECHO KNOB B6037H INCLUDED ACCESSORIES REF.NO. PARTS NO. DESCRIPTION REMARKS 9A08764000 OWNER'S MANUAL S1003 9A08764100 RCA CORD,AV S2655 ...
- Page 27 KEY UNIT OUTPUT UNIT REF.NO. PARTS NO. DESCRIPTION REF.NO. PARTS NO. DESCRIPTION 9A08763600 KEY UNIT 9A08767620 OUTPUT UNIT D501 9A08655600 UPD16311 D201 9A08767300 IC,74HCU04A PH501 9A08655700 FABSE1252 L201‑L205 9A08661700 INDUCTOR,3.3UH RP001 9A08662500 KHX3‑3W1D L206 9A08653700 INDUCTOR,BGH2012B601 S501‑S506 9A08655400 EVQ20504M L208 9A08661600 INDUCTOR,1.8UH U501 9A08655500 HS0038 ...
