TS200 Series Tripod Turnstile
Note: The turnstile's opening duration is set to 5s by default.

4.3.2Direction Indicator

It is to indicate whether people can pass through the gate. The green arrow means passing is
allowed while the red cross "X" means that passing is prohibited. The indicator status can be set with
number 4 and 5 in the DIP switch. The descriptions of the bit settings are as follows:
11 = Passing is allowed in both directions.
10 = One-way forbidden; right passing is allowed.
01 = One-way forbidden; left passing is allowed.
00 = Both ways forbidden.

4.3.3Continue Passing Function

With the "Continue Passing" function, the turnstile could remember at most 20 swipes of one card at
one time and allows up to 20 people to pass so they don't have to swipe card each time. This
function can be enabled or disabled with number 6 in the DIP switch. The descriptions of the bit
settings are as follows:
In the DIP switch, number 6 is used to enabled or disabled the Continue Passing Function; number
7 is used to set the initial value of Continue Passing Function.
Number Number
6 7
0 Disabled
1
1
0

4.3.4Alarm Function (Optional)

In the DIP K1 switch, number 8 is used to enabled or disabled the Alarm Function.
1 = enabled
P a g e | 11
Bit Setting Duration
111 5s
110 10s
101 15s
100 20s
Function
Disabled Continue Passing
Function
Enabled Continue Passing
Function
Bit Setting Duration
011 30s
010 40s
001 50s
000 60s
Opening Duration
Please refer to section
Turnstile Opening Duration.
The initial value is 16s, and the Opening
Duration = 16 + (N -1) * 6.
The initial value is 8s, and the Opening
Duration = 8+ (N -1) * 6.
User Manual
4.3.1 Setting the
