Honda ANC125 2019 Owner's Manual
  1. Manuals
  2. Brands
  3. Honda Manuals
  4. Scooter
  5. ANC125 2019
  6. Owner's manual

Honda ANC125 2019 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
ANC125

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANC125 2019 and is the answer not in the manual?

Questions and answers

Robert Gale
February 4, 2025

How do I recharge the battery without removing it from the scooter?

0
1 comments:
Mr. Anderson
February 10, 2025

The manual instructs to remove the battery from the scooter before charging. It also warns against using an automobile-type battery charger, as it can overheat the motorcycle battery and cause damage. Therefore, charging the battery without removing it is not recommended.

This answer is automatically generated

0

Related Manuals for Honda ANC125 2019

Summary of Contents for Honda ANC125 2019

  • Page 1 OWNER’S MANUAL ANC125...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Congratulations on your purchase of a new The following codes in this manual ● Honda scooter. Your selection of a Honda indicate each country. makes you part of a worldwide family of The illustrations here in are based on the ●...
  • Page 4 A Few Words About Safety Your safety, and the safety of others, is very DANGER important. Operating this scooter safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about WARNING safety, we have provided operating procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Scooter Safety P. 2 Operation Guide P. 16 Maintenance P. 44 Troubleshooting P. 85 Information P. 102 Specifications P. 113 Index P. 116...

  • Page 6: Scooter Safety

    Scooter Safety This section contains important information for safe riding of your scooter. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 10 Riding Precautions ..........P. 11 Accessories & Modifications......P. 14 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines that you and your passenger are both wearing an approved motorcycle helmet and protective Follow these guidelines to enhance your safety: apparel. Instruct your passenger on holding onto the grab rail or your waist, leaning with Perform all routine and regular inspections ●...
  • Page 8 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your scooter properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...
  • Page 9 Safety Guidelines If you decide to continue riding, first turn the Never run your scooter inside a garage or other ignition switch to the (Off) position, and enclosure. evaluate the condition of your scooter. Inspect WARNING for fluid leaks, check the tightness of critical nuts Running the engine of your scooter and bolts, and check the handlebar, control levers, brakes, and wheels.

  • Page 10: Image Labels

    Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 11 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.
  • Page 12 Image Labels RADIATOR CAP LABEL DANGER NEVER OPEN WHEN HOT. Hot coolant will scald you. Relief pressure valve begins to open at 108 kPa. ACCESSORIES AND LOADING WARNING LABEL WARNING ACCESSORIES AND LOADING • The safety stability and handling of this scooter may be affected by the addition of accessories and luggage.
  • Page 13 Image Labels TYRE INFORMATION & CARGO LIMIT LABEL For your protection, always wear helmet, protective apparel. Cold tyre pressure: [Driver only] Front 175 kPa (1.75 kgf/cm , 25 psi) Rear 200 kPa (2.00 kgf/cm , 29 psi) [Driver and passenger] Front 175 kPa (1.75 kgf/cm , 25 psi)

  • Page 14: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the floor. Not wearing a helmet increases the Keep passenger's hands onto the grab rail ●...

  • Page 15: Riding Precautions

    Riding Precautions Riding Precautions Exercise caution on low traction surfaces. ● The tyres slip more easily on such surfaces and braking distances are Running-in Period longer. During the first 500 km (300 miles) of running, Avoid continuous braking. ● follow these guidelines to ensure your scooter's Repeated braking, such as when future reliability and performance.
  • Page 16 Riding Precautions the shutter when leaving the scooter Wet or Rainy Conditions unattended. Road surfaces are slippery when wet, and wet Use of an anti-theft device is also brakes further reduce braking efficiency. recommended. Exercise extra caution when braking in wet conditions.
  • Page 17 Riding Precautions Refuelling and Fuel Guidelines Left handle grip Centre stand Follow these guidelines to protect the engine, Grab rail fuel system and catalytic converter: Use only unleaded petrol. ● Use recommended octane number. Using ● lower octane petrol will result in decreased engine performance.

  • Page 18: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your scooter by Honda or make Follow all instructions in this owner's modifications to your scooter from its original manual regarding accessories and design.

  • Page 19: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your scooter's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.

  • Page 20: Operation Guide

    Basic Operation Flow Pre-ride Inspection (P.49) Acceleration Carefully inspect your scooter to (P.36) make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. Starting the Engine (P.33) Start and warm the engine. How to use basic features. •...
  • Page 21 Parking (P.12) Braking Close the throttle and apply the (P.37) Park on a firm level surface. front and rear brakes together. The brakelight will indicate Use the stand, lock the that you have applied the steering and close the shutter. brakes.
  • Page 22 Parts Location Document bag (P.43) Centre compartment (P.42) Helmet holder (P.41) Throttle grip (P.81) Front brake fluid reservoir (P.74) CBS brake fluid reservoir (P.74) Data link connector Battery (P.61) Fuse box (P.100) Shopping hook (P.42) Tool kit (P.43) Engine oil drain bolt Engine oil fill cap/dipstick (P.68) (P.69)
  • Page 23 Rear brake lever (P.76) Helmet holder (P.41) Seat (P.40) Fuel fill cap (P.38) Rear carrier (P.40) Spark plug (P.65) Rear suspension spring preload adjuster (P.84) Crankcase breather (P.82) Oil plug (P.69) Centre stand (P.12) Side stand (P.80)
  • Page 24 Instruments button button TRIP CLOCK Fuel gauge Needle in the red (E) mark, remaining fuel approximately 1.49 L (0.394 US gal, 0.328 Imp gal). Speedometer This shows your speed in kilometer per hour (km/h) and/or miles per hour (mph) depend on type. Display Check When the ignition switch is turned to the (On) position, the speedometer and fuel gauge needles swing to the maximum scale on the dial once, all the mode and digital segments...
  • Page 25 Clock (12-hour display) To set the clock: (P.22) OIL CHANGE indicator ED type Comes on when the distance reaches about 1,000 km for the first time and every 8,000 km after resetting the indicator. E type Comes on when the distance reaches about Odometer [TOTAL] &...
  • Page 26 Instruments (Continued) To set the clock: Wait for 5 seconds and press CLOCK button. The clock is set. Turn the ignition switch to the (On) The time can also be set by turning the position. ignition switch to the (Off) position. Press and hold the button until the CLOCK...
  • Page 27 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. High coolant temperature indicator If it comes on while riding: (P.87) PGM-FI (Programmed Fuel Injection) malfunction indicator lamp (MIL) Comes on briefly when the ignition switch is turned to the (On) position.
  • Page 28 Indicators (Continued) Left turn signal indicator Right turn signal indicator Idling Stop indicator Comes on briefly when the Idling Stop switch in the IDLING STOP with the ignition switch turned to the (On) position. Idling Stop system: (P.30) High beam indicator...
  • Page 30 Switches Idling stop switch • IDLING STOP : The Idling Stop system is on. • IDLING : The Idling Stop system is off. Idling Stop system: (P.30) Start button Turn signal switch Pressing the switch turns the turn signal off. Horn button Headlight dimmer switch •...
  • Page 31 Ignition switch (On) Turns electrical system on Switches the electrical system on/off, for starting/riding. locks the steering, and operates the seat opener switch. OPENER Key can be removed when in the Operates the seat opener (Off) or (Lock) position. switch. (Off) Turns engine off.
  • Page 32 Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the (Lock) position. A U-shaped wheel lock or similar device is Jiggle the handlebar if the lock is difficult also recommended.
  • Page 33 Shutter Close Remove the ignition key from the ignition The ignition switch for this scooter is switch. equipped with a shutter. After parking the Align the projection of the shutter key with scooter, close the shutter for theft the slot of the shutter, and turn the shutter prevention.
  • Page 34 Idling Stop System Idling Stop system is designed to help reduce Activation of the Idling Stop System the fuel consumption and noise, by idling The Idling Stop system becomes ready to stop the engine and Idling Stop indicator stop while making a stop such as waiting at comes on when the following requirements an intersection.
  • Page 35 Stopping the engine by the Idling Stop Safety Precaution for the Idling Stop System System Do not go away from the scooter while the The engine stops and Idling Stop indicator Idling Stop indicator is flashing. When you go changes to flash after you close the throttle away from the scooter, always turn the completely and stop the scooter while the ignition switch to the...
  • Page 36 Idling Stop System (Continued) Restarting the Engine NOTICE Check that the Idling Stop indicator is Headlight stays on after the engine is stopped by the Idling Stop system. The battery may flashing, and then open the throttle. discharge and you may not be able to restart If it is not flashing, you can't restart the engine.
  • Page 37 Starting the Engine Start your engine using the following procedure, Consult your dealer for advice if you plan to regardless of whether the engine is cold or warm. ride your scooter at an altitude above 2,500 m (8,000 feet). This scooter is equipped with a side stand NOTICE ignition cut-off system.
  • Page 38 Starting the Engine (Continued) Place the scooter on its centre stand. Squeeze the rear brake lever. Turn the ignition switch to the (On) The starter motor will only work when position. the rear brake lever is squeezed and the Confirm the following: side stand is up.
  • Page 39 If the engine does not start: If you cannot start the engine: Open the throttle fully and press the start With the throttle slightly open (about 3 mm button for 5 seconds. (0.1 in) without freeplay), press the start Repeat the normal starting procedure. button.
  • Page 40 Riding Starting the Scooter Acceleration and deceleration To accelerate: Open the throttle slowly. Push the scooter forward off the centre stand. To decelerate: Close the throttle. Squeeze the rear brake lever. Close (Decelerate) Open (Accelerate) Keep throttle closed. Make sure the side stand and centre stand are up.
  • Page 41 Braking Close the throttle and apply the front and rear brake levers together. Rear brake lever Front brake lever...
  • Page 42 Refuelling Fuel type: Unleaded petrol only Arrow marks Fuel fill cap Fuel octane number: Your scooter is designed to use Research Octane Number (RON) 95 or higher. Tank capacity: 5.5 L (1.45 US gal, 1.21 Imp gal) Refuelling and Fuel Guidelines (P.13) Opening the Fuel Fill Cap Open the seat.
  • Page 43 Closing the Fuel Fill Cap Install and tighten the fuel fill cap firmly by turning it clockwise. Make sure that the arrow marks on the cap and fuel tank are aligned. Close the seat. WARNING Petrol is highly flammable and explosive.
  • Page 44 Storage Equipment Seat Open Seat Turn the handlebar pointed straight ahead. Seat opener Insert the ignition key and turn it to the switch OPENER position. Push the SEAT side of the seat opener switch. Open the seat. OPENER Seat Close Close and push down on the rear of the seat until locks.
  • Page 45 Helmet Holders WARNING The helmet holders are located under the Riding with a helmet attached to the seat. holder can interfere with your ability to Use the helmet holders only when parked. safely operate the scooter and could lead to a crash in which you can be seriously hurt or killed.
  • Page 46 Storage Equipment (Continued) A helmet can be stored in the centre Shopping Hook compartment. The shopping hook is provided below the Set in the front of the helmet forward. handlebar. Some helmets may not fit in the Do not attach large luggage to the hook compartment due to their size or design.
  • Page 47 Tool Kit Document Bag The tool kit is in the reverse side of the seat The document bag is in the document by the rubber strap. compartment in the centre compartment. Tool kit Document bag Rubber strap Document compartment...

  • Page 48: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 45 Throttle ..............P. 81 Maintenance Schedule........P. 46 Crankcase Breather ........... P. 82 Maintenance Fundamentals ......P. 49 Other Adjustments..........

  • Page 49: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your scooter well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task, and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 50: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your scooter after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 51 Inspect (clean, adjust, lubricate, or replace, if necessary) have the necessary tools and are mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your scooter serviced by your dealer.
  • Page 52 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 49 × 1,000 mi Final Drive Oil 2 Years – Battery – Brake Fluid 2 Years Brake Shoes/Pads Wear 75, 79 Brake System Headlight Aim Lights/Horn –...

  • Page 53: Maintenance Fundamentals

    Maintenance Fundamentals Brakes - Check operation; Pre-ride Inspection ● Front: check brake fluid level and pads wear. To ensure safety, it is your responsibility to P. 74, P. 75 perform a pre-ride inspection and make sure Combi Brake: check brake fluid level. P.
  • Page 54 Maintenance Fundamentals Replacing Parts Colour Label Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering coloured components, specify the model name, colour, and code mentioned on the colour label. The colour label is attached to the centre compartment under the seat.
  • Page 55 Maintenance Fundamentals Battery NOTICE Your battery is a maintenance-free type and can Your scooter has a maintenance-free type be permanently damaged if the cap strip is battery. You do not have to check the battery removed. electrolyte level or add distilled water. Clean the battery terminals if they become dirty or This symbol on the battery means corroded.
  • Page 56 Maintenance Fundamentals What to do in an emergency WARNING If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool A spark or flame can cause the battery water for at least 15 minutes.
  • Page 57 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher battery and possibly damaging the system.
  • Page 58 Selecting the Engine Oil circular API service symbol. For recommended engine oil, see “Specifications.” P. 114 If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MB ●...
  • Page 59 A concentration of up to 60% will provide better protection in colder climates. Recommended brake fluid: NOTICE Honda DOT 3 or DOT 4 Brake Fluid or Using coolant not specified for aluminium equivalent engines or tap/mineral water can cause corrosion.
  • Page 60 Maintenance Fundamentals Inspecting for Damage Crankcase Breather Inspect the tyres for Service more frequently when riding in rain, at cuts, slits, or cracks that full throttle, or after the scooter is washed or exposes fabric or overturned. Service if the deposit level can be cords, or nails or other seen in the transparent section of the drain foreign objects...
  • Page 61 Maintenance Fundamentals Inspecting Tread Depth WARNING Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.
  • Page 62 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres and air pressure, see Installing improper tyres on your “Specifications.” P. 114 scooter can adversely affect handling Follow these guidelines whenever you replace and stability, and can cause a crash in tyres.
  • Page 63 Maintenance Fundamentals Air Cleaner This scooter is equipped with a viscous type air cleaner element. Air blow cleaning or any other cleaning can degrade the viscous element performance and cause the intake of dust. Do not perform the maintenance. Should be serviced by your dealer.

  • Page 64: Tool

    Tool The tool kit is in reverse side of the seat. P. 43 You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools. Spark plug wrench ● 8 × 12 mm Open end wrench ● 10 ×...

  • Page 65: Removing & Installing Body Components

    Removing & Installing Body Components Battery Disconnect the negative - terminal from the battery. Bolts Washer Disconnect the positive + terminal from Battery band the battery. Remove the battery taking care not to drop the terminal nuts. Positive Installation terminal Negative Install the parts in the reverse order of terminal...

  • Page 66: Clip

    Removing & Installing Body Components Clip Clip Installation Removal Push the bottom of the centre pin. Insert the clip into the hole. Press down on the centre pin to release Press down on the centre pin to lock the the lock. clip.

  • Page 67: Front Centre Cover

    Removing & Installing Body Components Front Centre Cover Front Centre Cover Removal Remove the screws. Screws Front centre cover Remove the prongs A by pulling the under side of the front centre cover (a). Prongs B Be careful of the direction to pull and do not pull too much.

  • Page 68: Fuel Tank Cover And Rear Centre Cover

    Removing & Installing Body Components Fuel Tank Cover and Rear Centre Cover Fuel Tank Cover and Rear Removal Centre Cover Open the seat. P. 40 Remove the clips. P. 62 Remove the fuel tank cover. Clips Fuel tank cover Remove the rear centre cover. Rear centre Installation cover...

  • Page 69: Spark Plug

    Spark Plug Changing Spark Plug Prong For the recommended spark plug, see “Specifications.” P. 114 Use only the recommended type of spark plug in the recommended heat range. NOTICE Using a spark plug with an improper heat range can cause engine damage. Clips Left floor cover Place your scooter on its centre stand on...
  • Page 70 Spark Plug Changing Spark Plug Remove the screw and the clip. P. 62 Clean any dirt from around the spark plug Remove the bolt and release the under base. cover hole from the tab. Remove the spark plug using provided spark plug wrench.
  • Page 71 Spark Plug Changing Spark Plug Install the new spark plug. With the plug Install the parts in the reverse order of washer attached, thread the spark plug in removal. by hand to prevent cross-threading. When reinstalling the spark plug cap, Tighten the spark plug: take care to avoid pinching any cables Installing a new plug, tighten it twice...

  • Page 72: Engine Oil

    Engine Oil Checking the Engine Oil Oil fill cap/dipstick Upper level Check the engine oil with the Idling Stop switch at IDLING. If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the (Off) position and wait for 2 to 3 minutes.
  • Page 73 Engine Oil Adding Engine Oil Adding Engine Oil For the recommended oil and oil selection guidelines, see “Maintenance Fundamentals.” P. 54 If the engine oil is below or near the lower level mark, add the recommended engine oil. Changing Engine Oil, Cleaning P.
  • Page 74 Engine Oil Changing Engine Oil, Cleaning Strainer Screen Place your scooter on its centre stand on Sealing washer a firm, level surface. Place a drain pan under the drain bolt and oil plug. Remove the oil fill cap/dipstick, drain bolt and sealing washer to drain the oil.
  • Page 75 Engine Oil Changing Engine Oil, Cleaning Strainer Screen Install a new sealing washer onto the drain bolt. Tighten the drain bolt. Torque: 24 N·m (2.4 kgf·m, 18 lbf·ft) Fill the crankcase with the recommended oil ( P. 54, P. 114) and install the oil fill cap/dipstick.

  • Page 76: Coolant

    Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a serious leak. Have your scooter inspected by Check the coolant level in the reserve tank your dealer. while the engine is cold. Place your scooter on a firm, level surface.
  • Page 77 Coolant Changing Coolant Remove the clip. P. 62 Securely reinstall the reserve tank cap. Remove the reserve tank lid. Install the reserve tank lid and the clip. Remove the reserve tank cap and add Close the seat. fluid while monitoring the coolant level. Do not overfill above the UPPER level WARNING mark.

  • Page 78: Brakes

    Brakes Checking Brake Fluid Front brake Front brake fluid reservoir Place your scooter in an upright position on a firm, level surface. Check that the brake fluid reservoir is horizontal and that the fluid level is: above the LWR mark. Front brake between the LOWER level Combi brake...
  • Page 79 Brakes Inspecting the Front Brake Pads Inspecting the Front Brake Pads Inspect the brake pads from in front of the brake caliper. Check the condition of the brake pad wear If necessary have the pads replaced by your indicators. dealer. The pads need to be replaced if a brake pad Always replace both left and right brake pads is worn to the bottom of the indicator.
  • Page 80 Brakes Inspecting the Rear Brake Lever Freeplay Inspecting the Rear Brake Lever Check the brake cable for kinks or signs of wear. If necessary have it replaced by your Freeplay dealer. Lubricate the brake cable with a Place the scooter on its centre stand. commercially available cable lubricant to Measure the distance the rear brake lever prevent premature wear and corrosion.
  • Page 81 Brakes Adjusting the Rear Brake Lever Freeplay Adjusting the Rear Brake Lever Adjust by turning the rear brake adjusting nut a half-turn at a time. Freeplay Brake arm pin Adjust the freeplay of the brake lever with the front wheel pointed straight ahead. Increase Make sure the cut-out on the adjusting nut is Freeplay...
  • Page 82 Brakes Adjusting the Rear Brake Lever Freeplay Push the brake arm to confirm that there is a gap between the rear brake adjusting nut and brake arm pin. Brake arm Push Brake arm pin Adjusting nut After adjustment, confirm the freeplay of the brake lever.
  • Page 83 The rear brake is equipped with a brake wear the brake, the brake shoes must be replaced. indicator. See your dealer for this service. Arrow When the brake service is necessary, see your dealer. Use only Honda Genuine Parts or its equivalent. Reference mark Brake arm Brake panel...

  • Page 84: Side Stand

    Side Stand Checking the Side Stand Sit on the scooter and raise the side stand. Start the engine. Lower the side stand all the way. The engine should stop as you lower the side stand. If the engine doesn't stop, have your scooter inspected by your dealer.

  • Page 85: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly, close automatically, or if the cable is damaged, have the scooter inspected by your dealer.

  • Page 86: Crankcase Breather

    Crankcase Breather Cleaning the Crankcase Breather Place a suitable container under the crankcase breather tube. Remove the crankcase breather tube and drain deposits. Reinstall the crankcase breather tube. Crankcase breather tube...

  • Page 87: Other Adjustments

    Other Adjustments Adjusting the Headlight Aim You can adjust vertical aim of the headlight for proper alignment. Turn the pinion in or out as necessary. Using a Phillips screwdriver provided in the tool kit ( P. 60). Obey local laws and regulations. Lower Raise Pinion...

  • Page 88: Adjusting The Rear Suspension

    Other Adjustments Adjusting the Rear Suspension Adjusting the Rear Suspension NOTICE Attempting to adjust directly from 1 to 5 or 5 to 1 Spring Preload may damage the shock absorber. You can adjust the spring preload by the NOTICE adjuster to suit the load or the road surface. Do not turn the adjuster beyond its limits.

  • Page 89: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 86 Electrical Trouble ..........P. 93 Overheating (High coolant temperature Battery Goes Dead ..........P. 93 indicator is on) ..........P. 87 Burned-out Light Bulb........P. 93 Warning Indicators On........P. 88 Blown Fuse............P. 100 PGM-FI (Programmed Fuel Injection) Unstable Engine Operation Occurs Malfunction Indicator Lamp (MIL)....

  • Page 90: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 33 sequence.

  • Page 91: Overheating (High Coolant Temperature Indicator Is On)

    Overheating (High coolant temperature indicator is on) The engine is overheating when the following Stop the engine using the ignition switch. occurs: Allow the engine to cool with the ignition High coolant temperature indicator switch in the (Off) position. ● comes on.

  • Page 92: Warning Indicators On

    Warning Indicators On PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your scooter inspected by your dealer as soon as possible.

  • Page 93: When The Idling Stop System Does Not Operate Properly

    When the Idling Stop System Does Not Operate Properly Idling Stop Indicator Does Not If PGM-FI malfunction indicator lamp (MIL) lights: Come On When the PGM-FI malfunction indicator lamp (MIL) lights, the Idling Stop system does not When the Idling Stop indicator does not operate for protection of the engine.

  • Page 94: Engine Is Not Stopped By The Idling Stop System While The Idling Stop Indicator Is On

    When the Idling Stop System Does Not Operate Properly Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On Engine is Not Stopped by the Idling Stop System While the Idling Stop Indicator is On When the engine is not stopped by the Idling Stop system while the Idling Stop indicator is on, perform the followings.

  • Page 95: Engine Does Not Start Even If The Throttle Is Opened

    When the Idling Stop System Does Not Operate Properly Engine Does Not Start Even If the Throttle is Opened Engine Does Not Start Even If If the Idling Stop switch is at IDLING: While the engine is stopping by the Idling the Throttle is Opened Stop system, if you press the Idling Stop switch to IDLING, the Idling Stop system will...

  • Page 96: Tyre Puncture

    Tyre Puncture Repairing a puncture or removing a wheel WARNING requires special tools and technical expertise. Riding your scooter with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 97: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the scooter before Turn the ignition switch to the (Off) or charging.
  • Page 98 Electrical Trouble Burned-out Light Bulb Headlight Bulb Screws A Headlight Dust covers case Lock Lock Rearview mirrors Socket Screws B Mirror Mirror adapter adapter Remove the screws A and B. Pull up the dust covers. Remove the headlight case, then pull the Loosen the lock nuts by turning clockwise.
  • Page 99 Electrical Trouble Burned-out Light Bulb Install the rearview mirrors by turning counterclockwise until they will no longer turn. Loosen the rearview mirrors Arrow mark approximately 2 turns. Adjust the rearview mirrors. Tighten the lock nuts and install the dust covers. Do not touch the glass surface with your Bulb fingers.
  • Page 100 Electrical Trouble Burned-out Light Bulb Position Light Bulb Bulb Socket Remove the front centre cover. P. 63 Turn the socket counterclockwise and pull it out. Pull out the bulb without turning it. Install a new bulb and parts in the reverse order of removal.
  • Page 101 Electrical Trouble Burned-out Light Bulb Brakelight/Taillight and Rear Turn Screw B Screws B Signal Bulb Rear combi light Clip Prongs Prongs Screw B Connector License plate light cover Winker Remove the rear combi light by removing Clip Screws A covers the screws B and the prongs, then disconnect the connector.
  • Page 102 Electrical Trouble Burned-out Light Bulb Brakelight/Taillight Bulb Socket A Turn the socket A counterclockwise and pull it out. Slightly press the brakelight/taillight bulb in and turn it counterclockwise. Install a new bulb and parts in the reverse order of removal. Rear Turn Signal Bulb Turn the socket B counterclockwise and pull it out.
  • Page 103 Electrical Trouble Burned-out Light Bulb Front Turn Signal Bulb License Plate Light Bulb Bulb Socket Cover Bulb Screws Remove the front centre cover. P. 63 Remove the license plate light cover. Turn the socket counterclockwise and pull it out. P. 97 Pull out the bulb without turning it.

  • Page 104: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Remove the front centre cover. P. 63 Pull out the fuse box cover. Pull the main fuse and other fuses out Before handling fuses, see “Inspecting and one by one with the fuse puller in the Replacing Fuses.”...

  • Page 105: Unstable Engine Operation Occurs Intermittently

    Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your scooter. If unstable engine operation occurs even if sufficient fuel is available, have your scooter inspected by your dealer as soon as possible.

  • Page 106: Information

    Information Keys..............P. 103 Instruments, Controls, & Other Features... P. 104 Caring for Your Scooter......... P. 104 Storing Your Scooter........P. 107 Transporting Your Scooter ......P. 108 You & the Environment ......... P. 109 Serial Numbers ..........P. 110 Fuels Containing Alcohol ......

  • Page 107: Keys

    Keys Keys Ignition Key Be sure to record the key number provided with the key number plate. Store the spare key and key number in a safe location. To make a duplicate, take the spare key or the key number to your dealer. Ignition key Key number plate If you lose all ignition keys and the key number,...

  • Page 108: Instruments, Controls, & Other Features

    Instruments, Controls, & Caring for Your Scooter Other Features Frequent cleaning and polishing is important to ensure the life of your Honda. A clean scooter Ignition Switch makes it easier to spot potential problems. Leaving the ignition switch in the (On) position In particular, seawater and salts used to prevent with the engine stopped will drain the battery.
  • Page 109 Caring for Your Scooter Thoroughly rinse your scooter with plenty of Washing Precautions clean water and dry with a soft, clean cloth. Follow these guidelines when washing: After the scooter dries, lubricate any moving Do not use high-pressure washers: ● parts.
  • Page 110 Caring for Your Scooter Do not direct water at the air cleaner: Aluminium Components ● Water in the air cleaner can prevent the Aluminium will corrode from contact with dirt, engine from starting. mud, or road salt. Clean aluminium parts Do not direct water near the headlight: ●...

  • Page 111: Storing Your Scooter

    Storing Your Scooter Storing Your Scooter Panels Follow these guidelines to prevent scratches If you store your scooter outdoors, you should and blemishes: consider using a full-body motorcycle cover. Wash gently using a soft sponge and plenty ● If you won't be riding for an extended period, of water.

  • Page 112: Transporting Your Scooter

    Transporting Your Scooter Transporting Your Scooter After removing your scooter from storage, inspect all maintenance items required by the If your scooter needs to be transported, it Maintenance Schedule. should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform, and motorcycle tie-down straps.

  • Page 113: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a scooter can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 114: Serial Numbers

    Serial Numbers Serial Numbers Frame number The frame and engine serial numbers uniquely identify your scooter and are required in order to register your scooter. They may also be required when ordering replacement parts. Rear fender lid To check the frame number, remove the clip P.

  • Page 115: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol The use of petrol containing more than 10% ethanol may: Some conventional fuels blended with alcohol Damage the painting of the fuel tank. ● are available in some locales to help reduce Damage the rubber tubes of the fuel line. ●...

  • Page 116: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 117: Specifications

    Specifications Main Components ■ Displacement 125 cm (7.62 cu-in) Overall length 1,930 mm (76.0 in) Bore x stroke 52.4 x 57.9 mm (2.06 x 2.28 in) Overall width 665 mm (26.2 in) Compression ratio 11.0:1 Unleaded petrol Overall height 1,105 mm (43.5 in) Fuel Recommended: 95 RON or higher Wheelbase...
  • Page 118 Moped Not Permitted disassembly Front 175 kPa (1.75 kgf/cm , 25 psi) Tyre air pressure Recommended Honda DOT 3 or DOT 4 Brake Fluid (Driver only) Rear 200 kPa (2.00 kgf/cm , 29 psi) brake fluid Tyre air pressure Front 175 kPa (1.75 kgf/cm...
  • Page 119 Specifications Bulbs Torque Specifications ■ ■ Headlight 12 V-35/35 W Engine oil drain bolt 24 N·m (2.4 kgf·m, 18 lbf·ft) Brakelight/Taillight 12 V-21/5 W Oil plug 20 N·m (2.0 kgf·m, 15 lbf·ft) Front turn signal 12 V-10 W × 2 Rear turn signal 12 V-10 W ×...

  • Page 120: Index

    Index Clock ..............21 Accessories ............14 CLOCK button........... 20 Colour Label............50 Compartment Basic Operation Flow ........16 Document Bag .......... 43, 104 Battery............51, 61 Owner’s Manual ........43, 104 Brakes Tool Kit..............43 Brake Lever Freeplay......... 76 Coolant............
  • Page 121 Idling Stop Switch ........26, 30 Flooded Engine ..........33 Idling Stop System .......... 30 Frame Number ..........110 Ignition Cut-off System Fuel Side Stand............80 Gauge ..............20 Ignition Key............. 103 Recommended ........... 38 Ignition Switch ......... 27, 104 Remaining............
  • Page 122 Front Centre Cover..........63 Odometer..........21, 104 Fuel Tank Cover..........64 Rear Centre Cover ..........64 Engine ............54, 68 Repair Kit ............92 OIL CHANGE indicator........21 Riding Precautions .......... 11 Overheating ............87 Safety Precautions........... 10 Parking ............... 12 Seat ..............
  • Page 123 Storage Centre Compartment........42 Warning Indicator On........88 Document Bag............ 43 Washing Your Scooter........104 Equipment ............40 Weight Limit..........15, 113 Helmet Holders ..........41 Rear Carrier ............40 Shopping Hook ..........42 Storing Your Scooter ........107 Switches ............. 26 Throttle...............
  • Page 125 32K29B30 XXX.XXXX.XX.K 00X32-K29-B300 PRINTED IN XXXXX...
