RIB MINI WIRELESS Instruction Manual page 14

4
LEARNING
4.1 Learning transmitter through the learning key of the control unit
MINI WIRELESS control unit can be operated by all remotes WIRELESS series.
a
c
b
4.2 Learning subsequent transmitters with a transmitter already learned
Warning: Do not use this procedure if you have multiple units in operation, since the store opening would affect all devices where the channel is
stored. In this case, disconnect the power supply of the control units which shall not be involved.
1. Opening of memory: to open the memory from the transmitter, refer to the instructions enclosed to the transmitter. Once you
open the control unit memory, it indicates this by turning on the red LED.
2. Press "a" of the transmitters. The control unit also automatically memorize the key "b" and the "c" key ("a" like button "open",
"b" how "close" button and "c" as a "stop" button). The control unit signals the memorization of the channel with 2 flashings
if the channel was not memorized, with 1 if the channel was already learned.
3. Once memorized the channel, the control unit goes back to normal modality of functioning. If no signal is transmitted by 20
seconds, the control unit automatically exits from the learning mode.
Warning: keys functions are only valid with the DIP4 in OFF position (see 6.2.4)
1. Press and release the learning key on the card; the red LED lights up.
2. Press "a" of the transmitter. The control unit also automatically memorize the key "b" and the
"c" keys ("a" like button "open", "b" how "close" button and "c" as a "stop" button). The control
unit signals the memorization of the channel with 2 flashings if the channel was not memorized,
with 1 if the channel was already learned.
3. Once memorized the channel, the control unit goes back to normal modality of functioning.
If no signal is transmitted by 20 seconds, the control unit automatically exits from the learning
mode.
Warning: keys functions are only valid with the DIP4 in OFF position (see 6.2.4)
14
