Functions & configuration
Light control in front of the cell
It is possible to install a light switch in front of the prison cell for switching on the light. For further in-
formation, see "Wiring example" on page
Light withdrawal
Via ICX messages or the control desk, it is possible to activate light withdrawal for each prison cell in-
dividually so that the light can no more be switched on in the cell. In this case, the function "light at
attendance" is still available
switched on permanently so that it is no longer possible to switch off the light in the cell.
The function "light permanently on" is only available with the input "indicator status light". If the "in-
dicator status light" input is not activated after switching "attendance", the latching relay will be ener-
gised every ten seconds until the input is activated.
Light withdrawal
Commands from the Intercom Server
Activate light withdrawal
Deactivate light withdrawal
Retrieve light withdrawal status
Messages from the Intercom Server
Light withdrawal inactive
Light withdrawal active
Light permanently on
Commands from the Intercom Server
Activate light withdrawal
Deactivate light withdrawal
Retrieve light withdrawal status
Messages from the Intercom Server
Light withdrawal inactive
Light withdrawal active
18
16.
(see "Light at attendance" on page
Task
45
45
45
Task
45
45
Task
45
45
45
Task
45
45
17). Furthermore, the light can be
Type Parameter 1
7E Call number cell
7E Call number cell
7E Call number cell
Type Parameter 1
51 Call number cell
51 Call number cell
Type Parameter 1
7E Call number cell
7E Call number cell
7E Call number cell
Type Parameter 1
52 Call number cell
52 Call number cell
EB8E4A
Parameter 2
9004
9005
9006
Parameter 2
0000
0001
Parameter 2
9008
9009
900A
Parameter 2
0000
0001
