Clover TFT1914Q Specifications

19" TFT LCD Color Monitor
TFT LCD Monitor
19"
Front
Remote
Controller Outdoor Cameras
Specification
Monitor
Monitor type TFT LCD
Viewable screen size 19"
Resolution 1280x1024 at 60 to 75Hz
Pixel Format RGB vertical stripe
Pixel Pitch 0.294(H) x 0.294 (V) mm
Contrast Ratio 500:01:00
Brightness 400cd/m²
Video Input 1.0Vp-p composite video
4 Din jacks & 4 BNC connectors
Video Output 1.0Vp-p composite video
Input Impedance 75 ohms
Dwell Time Programmable 0 to 10 sec
AC Power Source AC 90V to 240V, 50/60Hz
Power Consumption 70W
Operation Temp 32ºF to 104ºF
Dimensions 20.6" (W) x 15.8" (H) x 2.9"(D)
Weight 20Lbs
ELECTRONICS USA
Quility Price Service Synergy
www cloverusa com
• LCD Screen • 4 Color CCD Cameras
CLOVER Proudly Presents 19" Color TFT LCD Monitor
Side
Day/Night
Cameras
13073 E. 166th St.
Cerritos, CA 90703
T: 562-282-5700
F: 562-282-5800
877-327-5000 (Toll Free)
WALL WALL
Mount Mount
Indoor
Camera
Image sensor
Resolution
Current Consumption
Electronic Iris
Lens
BABY WATCH OFFICE
PACKAGE INCLUDES :
MODEL# TFT1914Q
1- 19" TFT LCD Monitor
2- Indoor Cameras
2- Outdoor Day/Night Cameras
1- Remote Controller
MONITOR FEATURES:
• 19" TFT LCD Monitor
• High Resolution 1280x1024 @60 to 75 Hz
19"
• Contrast Ratio 500:1
• Brightness 400cd/m²
• 4 Video Inputs & 4 Looping Outputs
• Remote Controller
• 1 Ch Audio In & Out
Crystal
Clear
1/3" Color CCD, 270 pixels
330 TV Lines
120mA
NTSC: 1/60 to 1/100,000 Sec
PAL: 1/50 to 1/100,000 Sec
4.0mm C-Mount Lens
Back Light Compensation, AWB & AGC
60' Cable & Mounting Bracket
HOME SECURITY
1- Remote Controller
4- 60' 6 pin Din Cable
1- AC Power Cable
1- Instruction Manual
1- Warranty Registration Card
AUDIO
SUPPORTED
LOST PREVENTION
