Clover TFT1504Q Specifications

15" TFT LCD Monitor Built-in w/ 4 Cameras
15"
Front
Cameras
ELECTRONICS USA
Quility Price Service Synergy
www cloverusa com
Side
Specification
Monitor
Viewable screen size
Input Impedance
AC Power Source
Power Consumption
Operation Temp
Camera
Current Consumption
PACKAGE INCLUDES :
13073 E. 166th St.
Cerritos, CA 90703
MODEL# TFT1504Q
T: 562-282-5700
F: 562-282-5800 1- 15" TFT LCD Monitor built-in
4 ch Quad Spiller
877-327-5000 (Toll Free)
2- Indoor Cameras w/C-mount Lens
2- Outdoor Day/Night Cameras
4- 60' 6 pin Din cable
FEATURES:
• 15" TFT LCD Monitor
• High Resolution 1024x768 @60 to 75 Hz
• Contrast Ratio 350:1
• Brightness 450cd/m²
• Real Time 30 Frames/sec
• Picture In Picture, POP
• Anti-Roll Line Lock
• Video Loss Detection
• On Screen Display
• 2 Way Audio
• VCR Record-able
Monitor type TFT LCD Panel
15"
1024x768 at 60 to 75Hz
Resolution
30 Frames/sec
Real Time
350:1
Contrast Ratio
450cd/m²
Brightness
1.0Vp-p composite video
Video Input
4 Din jacks & 4 BNC connectors
Video Output
1.0Vp-p composite video
75 ohms
Dwell Time
Programmable 0 to 10 sec
AC 90V to 240V, 50/60Hz
40W
32ºF to 104ºF
Dimensions
15.2" (W) x 13" (H) x 2.5"(D)
Weight 31Lbs
Image sensor 1/3" Color CCD, 270 pixels
Resolution 330 TV Lines
120mA
Electronic Iris NTSC: 1/60 to 1/100,000 Sec
PAL: 1/50 to 1/100,000 Sec
Lens 4.0mm C-Mount Lens
Back Light Compensation, AWB & AGC
60' Cable & Mounting Bracket
2 - Mounting bracket &
2-built-in Mounting bracket
1- AC power cable
4- Manual
1- Warranty Registration Card
