Page 1
INFRA-RED RECEIVER MICROPHONE MENU ® : Receives signal from remote controller to the monitor. 2. MENU Button : After pressing this button, user can go into the “SETUP” Menu. To select any of Menu items, press the button again. This button is also used by down arrow key in Sub-Menu. 3.
Page 2
Configuration of the Rear Panel CAMERA 2 CAMERA CAMERA 1 CAMERA INPUT 1~4 : Channel 1~4 camera Inputs (6 Pins Din Connectors) VCR IN : To receive video signal from an external source(VCR or DVR) MONITOR OUT: To transmit video signal from the Monitor to a Slave monitor. VCR OUT: To transmit video signal from the Monitor to a VCR or DVR AUDIO IN: To receive audio signal from an external source AUDIO OUT: To transmit audio signal from the Monitor to an external source...
