Install a SIM/SD Card

Insert a Nano SIM/microSD card
1 . Insert a fingernail into the small slot at the bottom right corner of the device
and gently pull to remove the back cover of the phone .
Note: The back cover cannot be removed while the charger is plugged in .
2 . On the back of the phone, slide the Nano SIM card into the SIM card slot at
the top left with the gold contacts facing down .
3 . Slide the microSD card into the SD card slot at the top right .
4 . Replace the back cover and press gently until it snaps into place .
Mount an SD card
1 . With an SD card inserted, swipe up from the Home screen to access Apps
and tap Settings
2 . Tap Storage
3 . Tap MOUNT on the prompted screen .
.
> SD CARD .
