Cleveland SteamCub 1SCEMCS Specifications page 2

WATER QUALITY REQUIREMENT
The recommended minimum water quality standards whether
untreated or pre-treated, based upon 10 hours of use per day,
and a Daily Blowdown, are as follows:
TOTAL DISSOLVED SOLIDS less than 60 parts per million
TOTAL ALKALINITY
SILICA
pH FACTOR
CHLORINE
21.625"
549mm
17.434"
443mm
24.858"
FRONT
631mm
VIEW
30.890"
785mm
1.574"
40mm
ELECTRICAL
WATTS VOLTS PHASE WIRES
D
Standard Wattage
Three Phase - 9 kW Standard
C C1 C2
9400 208 3 3
9400 240 3 3
9400 480 3 3
H
Optional Low Wattage
Three Phase - 6 kW option
6400 208 3 3
6400 240 3 3
6400 480 3 3
*
For supply connection use only copper wire suitable for at least 75˚C. (167˚F).
Note: Consult local authorities for venting and installation requirements.
∗
For supply connection use only copper wire suitable for at least 75°C (167°F).
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are U.L/NSF#4 and CSA (AGA, CGA).
less than 20 parts per million
less than 13 parts per million
greater than 7.5
less than 30 parts per million
CYCLE SUPPLY CONNECTION
AMPS
HERTZ WIRE SIZE (COPPER)*
60 26.1 10
60 22.6 10
60 11.4 14
60 17.8 12
60 15.4 12
60 7.7 14
Consult a local water treatment specialist for an on site water
analysis for recommendations concerning steam generator
feed water treatment (if required), in order to remove or
reduce harmful concentrations of minerals. The use of high-
ly mineralized water will mean that more frequent servicing of
the steam generator will be necessary. The fact that a water
supply is potable is not proof that it will be suitable for the
generator.
23.100"
587mm
RIGHT
SIDE VIEW
1.500"
38mm
25.361"
644mm
WATTS VOLTS PHASE
Standard Wattage
Single Phase - 9 kW Standard
9400 208
9400 240
Optional Low Wattage
Single Phase - 6 kW option
6400 208
6400 240
•
Compartment has capacity for:
Five, 12˝ x 20˝ x 2 1 ⁄ ˝ deep Cafeteria Pans.
2
REAR
VIEW
2.100"
53mm
CYCLE
WIRES AMPS
HERTZ
1 2 60 45.2
1 2 60 39.2
1 2 60 30.8
1 2 60 26.7
SUPPLY CONNECTION
WIRE SIZE (COPPER)*
6
8
8
10
(NOT TO SCALE)
I 2
SECT. PAGE
0707
Litho in U.S.A.
