Cleveland 1SCE Specifications

™
Cleveland
STEAMCUB™ BOILERLESS
CONNECTIONLESS STEAMER
TM
SteamCub Plus
PRESSURELESS STEAM COOKER,
RETHERMALIZER & HOLDING CABINET
Cleveland Standard Features
I
Boilerless Pressureless Steam Cooker, Holding Cabinet and
Rethermalizer.
I
Capacity: Full Size Steam Table Pans:
Five: 2 1/2" x 12" x 20" (1/1 GN, 65mm)
•
Ten: 1" x 12" x 20" (1/1GN, 40mm)
•
I
Easy installation, no drain line, water connections or hood is
needed.*
I
Programmable Preheat and Holding Cycle Temperature
Controls with Compensating Thermostat.
Timer settings for 10 minute, 1 minute or 10 second intervals
•
Digital Time-Temperature and Low Water Indicator Display
•
I
Three Versatile Operating Modes.
Steam and Hold
•
Holding Only: Preset at 160˚ F (71˚ C)
•
Constant Steaming
•
I
6" (152mm) Skid Resistant Stainless Steel Adjustable Legs
with Flanged Feet.
I
8 gauge stainless steel inner cooking compartment, 14
gauge stainless steel outer compartment with two piece
compartment door for an airtight, leak-proof seal.
I
9 kW total output, with easy to remove 1 kW heating
elements (9ea) cast into aluminum bocks.
I
Electronic Low-Water Shut-Off Safety Indicator with audible
alarm, High Temperature Safety Shut-Off and LED "Heat On"
Indicator Light.
I
Separate Power ON/OFF Control includes an Automatic Pre-
Heat when power is turned "ON".
I
Easy-Access Manual Drain Valve located in front, Pan Slide
Guides located under unit to fit 12" x 20" (1/1GN) Pans.
Includes one 4" x 12" x 20
I
Approvals: cUL, NSF #4.
Options & Accessories
Ë Equipment Stand Model UniStand34.
Ë POSK Pull-Out Shelf Kit for UniStands (P/N 111724)
Ë URK Pan Rack Kit UniStands (P/N 111726)
Ë Optional Voltages, 480 Volt (VOS2).
Ë 6 kW total Output Six - 1kW heating elements.
Ë Single Phase Operation.
*
Consult local authorities for venting requirements
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900 Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782 Email: Steam@ClevelandRange.com
MODEL: 1SCE
Short Form Specifications
Shall be a Cleveland SteamCub Plus™ , Model 1SCE, one compartment
counter top steamer, holding cabinet and rethermalizer model number 1SCE.
Electronic controls with three operating modes: constants steaming, steam-
hold and holding only. 9 kW, 208 volts, 3 phase. Audible low water and high
temperature safety indicator. 8 gauge stainless steel inner cooking compart-
ment, 14 gauge stainless steel outer compartment with two piece compart-
ment door.
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
I
SECT. PAGE
0707
3
