Panasonic CS-Z50XKEW Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Air Conditioner
  5. CS-Z50XKEW
  6. Service manual

Panasonic CS-Z50XKEW Service Manual

Hide thumbs Also See for CS-Z50XKEW:
Table of Contents

Advertisement

Quick Links

Please file and use this manual together with the service manual for Model No. CS-Z20XKEW, CU-Z20XKE, CS-Z25XKEW,
CU-Z25XKE, CS-Z35XKEW, CU-Z35XKE, CS-Z42XKEW, CU-Z42XKE, CS-XZ20XKEW, CS-XZ25XKEW, CS-XZ35XKEW,
Order No. PAPAMY2101002CE.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
R32 REFRIGERANT
– This Air Conditioner contains and operates with refrigerant R32.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.
Refer to National, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation,
maintenance and/or service of this product.
CS-Z50XKEW
CS-Z71XKEW
WARNING
IMPORTANT SAFETY NOTICE
PRECAUTION OF LOW TEMPERATURE
CAUTION
Order No: PAPAMY2103012AE
Indoor Unit
© Panasonic Corporation 2021.
Outdoor Unit
CU-Z50XKE
CU-Z71XKE
Destination
Europe
Turkey
in the Schematic
