Service Manual

8.2 5 Ton

Fan motor
Heat sink
Figure 6
Bosch Thermotechnology Corp. | 07.2021
T5
HPS
T3
T3L
PT
Condenser
EEV
Tf
T4
Note: Please reference Table 18 for abbrevia on and parts descrip on.
RV
Compressor
Accumulator
Th
PEV
Bosch IDS 2.0 | 27
Data subject to change
