2 6 | Bosch IDS 2.0

8 Layout of Functional Components

8.1 3 Ton

Fan motor
Heat Sink
Figure 5
Data subject to change
PCB
HPS
T5
T3L
PT
Condenser
EEV
Tf
T4
Note: T3 not shown in figure, but is located on the condenser coil.
Please reference Table 18 for abbrevia on and parts descrip on.
RV
Compressor
Accumulator
Th
PEV
Service Manual
07.2021 | Bosch Thermotechnology Corp.
