Base Faucet Assemblies
1
Faucet Body Assembly w/ Eterna Cartridges
2
Faucet Body Assembly w/ Cerama Cartridges
2
Asm, Quarter-Turn Eterna Cartridge, RTC (new style)
3
Asm, Quarter-Turn Cerama Cartridge, RTC (new style)
3
Cartridge Only, Eterna w/ Spring Checks, RTC
3
Cartridge Only, Cerama w/ Check Valves, RTC
4
Asm, Quarter-Turn Eterna Cartridge, LTC (new style)
2
Asm, Quarter-Turn Cerama Cartridge, LTC (new style)
5
Cartridge Only, Eterna w/ Spring Checks, LTC
5
Cartridge Only, Cerama w/ Check Valves, LTC
6
Handle, Lever
4
Handle, Wrist Action
7
Screw, Handle
8
Index, Button - Hot (Red)
9
Index, Button - Cold (Blue)
10
Washer, Body
11
Locknut, Shank
12
Lock Washer, EasyInstall
13
Flexible Connector Hoses
Riser Assembly
14 Nipple, 3/8" x 24"
15 Swivel Assembly, EasyInstall
16
Swivel Piece
17
O-Ring, Swivel Piece
18 Asm, Finger Hook & Screw
19 Wall Bracket, 6" (add -B to model # for wall bracket)
Pre-Rinse Unit Assembly
20 Spring Body
21 Spring, Overhead
22 Asm, Flexible Stainless Steel Hoses
23 Asm, Spray Valve
Spray Valve Assembly
24 Washer, Hold Down Assembly
25 Ring, Hold Down Assembly
26 Body, Spray Valve (no handle)
27 Handle
28 Nut, Handle
29 Screw, Handle
30 Nipple
31 Cup, Spray
32 Ring, Sprayhead
*
33 Sprayface
*
34 Screw, Sprayface
*
Bonnet Assembly
35 Asm, Bonnet
36
Stem
*
37
Washer, Seat
*
38
Washer, Bonnet Binding
*
39
Bonnet
40
Washer, Bonnet Brass
*
41
Stem, Packing
*
42
Spring, Bonnet
*
43
Push Button
44
Grease Pack (o-ring lubricant)
*
* Parts included in B-10K parts kit
B-0200-LN
B-0200-CR-LN
002712-40NS
012446-25NS
35
012443-40NS
012394-25NS
002711-40NS
012447-25NS
012442-40NS
012395-25NS
001638-45NS
B-WH4-NS
000925-45
001193-19NS
018506-19NS
002290-45
000965-45
014200-45
43
012534-45
000372-40
EZ-K
N/A
001065-45
40
004R
B-0109-01
000821-40
000888-45
B-0044-H
B-0107
010476-45
000907-45
000065-40
001120-45
003198-45
003199-45
000694-40
000019-40
007861-45
001121-45
000913-45
002856-40
OPTIONAL (-B Models)
Wall Bracket Installation:
001097-45
1.
Fasten wall fl ange to
012915-45
wall using wall mount
001040-45
screws
000608-25
2.
Place 2-piece clamp as-
000974-45
sembly around riser and
001100-45
tighten clamp screws
000895-45
securely.
3.
Tighten set screws
000753-25
securely.
012665-45
25
27
24
26
30
28
31
29
32
33
34
42
44
41
40
39
38
37
36
8
8
2
2
1
12
3
3
Set Screws (2)
19
Clamp
Screws (2)
21
22
24
20
14
23
18
9
7
15
5
6
16
6
4
17
7
5
1
10
11
13
