Limited One Year Warranty
(Commercial Applications)
T&S warrants to the original purchaser (other
than for purposes of resale) that such product is
free from defects in material and workmanship
for a period of one (1) year from the date of
purchase. During this one-year warranty period,
if the product is found to be defective, T&S shall,
at its options, repair and/or replace it. To obtain
warranty service, products must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S
and the return of repaired or replaced product
to the purchaser are the responsibility of the
purchaser. Repair and/or replacement shall be
made within a reasonable time after receipt by
T&S of the returned product. This warranty does
not cover Items which have received secondary
fi nishing or have been altered or modifi ed after
purchase, or for defects caused by physical
abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein, and
any remedy for Breach of Contract which might
arise, is hereby excluded and disclaimed. Any
implied warranties of merchantability or fi tness
for a particular purpose are limited to one year in
duration. Under no circumstances shall T&S be
liable for loss of use or any special consequential
costs, expenses or damages.
Some states do not allow limitations on how
long and implied warranty lasts or the exclusion
or limitation of incidental or consequential
damages, so the above limitations or exclusions
may not apply to you. Specifi c rights under this
warranty and other rights vary from state to state.
Attention California Residents:
"WARNING: This product contains chemicals
known to the State of California to cause cancer,
and birth defects or other reproductive harm."
P/N: 098-003159-45 Rev.3
Date: 10-31-17
Drawn: TEH
Checked: JRM 11-27-17
Approved: JHB 12-01-17
Installation and
Maintenance
Instructions
B-16-K Parts Kit
B-0101 Pre-Rinse Spray
Español:
ES
Instrucciones de instalación y mantenimiento
Français:
FR
Instructions pour l'installation et la maintenance
Deutsch:
DE
Installations- und Wartungsanleitungen
中文:
CN
安装与维护说明

Advertisement

loading

Summary of Contents for T&S B-16-K

  • Page 1 Any express warranty not provided herein, and B-16-K Parts Kit any remedy for Breach of Contract which might arise, is hereby excluded and disclaimed. Any implied warranties of merchantability or fi tness...
  • Page 2: Exploded View

    Exploded View...
  • Page 3: Part Number Guide

    Part Number Guide Pre-Rinse Assembly Asm, Body, Valve 002857-40 Body, Valve O-Ring, Bonnet 001063-45 Spring 000894-45 000622-40 Insert, Spray Valve Quad Ring Washer, Bonnet 000974-45 Asm, Stem Washer, Seat 001094-45 O-Ring, Insert 001062-45 Cap, Hex 000623-40 Washer, Gooseneck Tip 001043-45 Asm, Spray Head B-0103 Washer, Ring...
  • Page 4 10,9 stem seat holder tallo sostén del aciento Le Tuyau Le Lieu Où Rester Le Joint Schaft D’Étanchéité 阀杆 Halter der Aufl agefl äche 阀座 To replace worn parts: 1. Shut off water supply and drain lines. Hold no.2 in one hand, with no.5 in palm and unscrew no.12 at bottom of no.1 with a wrench.
  • Page 5 15 16 5. Unscrew no.5 and remove from no.2. Discard old no.6 and replace with new no.6. Place no.3 on top of no.6, under new no.4. Place no.5 on top of no.4, loosely. 6. Hold no.5 (in place) and no.2 in one hand, push and screw no.9 up through no.2 until snug. 7.
  • Page 6 RELATED T&S BRASS PRODUCT LINE B-0106 Spray Valve with Brush and 44” Flexible Stainless Steel Hose B-0102-C Pot & Glass Filler, 90° Nozzle with Aerator and 68” Flexible Stainless Steel Hose T&S BRASS AND BRONZE WORKS, INC. A fi rm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O.
