Microsensor MPM4881 Operation Manual page 6

Pressure transmitting controller; differential pressure transmitting controller
Table of Contents

Advertisement

Accuracy:≤±0.25%FS;≤±0.5%FS;
Repeatability:
≤±0.2%FS;
Display: 4 digit 0.56 inch 14-segment LED display;
Temperature Drift: ≤±0.03%FS/℃(zero/span);
Display Refresh: 200ms.
Analog Output
Current Version: 4mA~20mA DC, Load resistance ≤560Ω;
Voltage Version: 0V~10V DC, Load resistance ≥10kΩ.
Switch Output
Output Mode: 5 relays, normally open or close contact;
Voltage Supply: ≤277V AC;≤30V DC;
Current Supply: ≤3A;
Response: < 1ms;
Relay Life: ≥10,000,000times/load (min.);≥100,000times/load
(max.);
Switch Point Setting: 1.5%FS~99%FS;
Return Difference Setting: 1%FS~10%FS;
3
