Switchable analog output

Record the Max. pressure during operation(button for

clearing up)
Support back, rail, cover and joint mounting

Hardware wrong operation protection

Intrinsically safe products meet GB3836.1 and GB3836.4

standards, and have explosion-proof certification, Exia
mark is Ex ib IIA T6 Gb.
Modbus communication


2 Specifications

Input
Power Supply: Non Intrinsically Safe： (220±44)V AC/22V~32V
DC;
Intrinsically Safe：22V~28V DC（Supplied by Safety Barrier）
Pressure Range:
0kPa~35kPa... 3.5MPa(MDM4881);
Overpressure: 1.5FS ;
Static Pressure: 20MPa (MDM4881)
Output
0kPa~10kPa..60MPa(MPM4881);
