Summary of Contents for ETCR 6100

  • Page 3: Table Of Contents

    CONTENT Warning ....................1 I Introduction ................... 3 II Electrical Signs ..................3 IV Technical Specifications..............4 V Structure ....................5 VI LCD Display ..................5 VII Operating Method................6 1. Start-up, Shutdown................ 6 2. AC/DC measurement switch ............6 3.
  • Page 4: Warning

    Warning Thank you for purchasing our company's High Accuracy AC/DC Clamp Leaker, for better use of this product, please: ——Read carefully the user's manual. ——Follow strictly safety rules and notes listed in this manual. u Under any circumstances, please pay special attention to your safety in course of using this leaker.
  • Page 5 u Users shall carry out operation based on danger signs “ ” on leaker manual. u Users shall carry out safety operation based on instructions listed in this manual, e.g. “ ” and danger signs on this manual. u Please use am to test leakage current (test by clamping grounding line, single-phase line together).
  • Page 6: I Introduction

    I Introduction High Accuracy Clamp Leaker is specially designed for measurement of AC/DC current; by adopting up-to-date CT technology and digital integration technology. There is no exposed metal on clamp head, non-contact measurement, to ensure safe operation. It is a product with relatively small size, high accuracy and perfect function compared with similar leakers in the world.
  • Page 7: Technical Specifications

    Ⅲ. Range and Accuracy Function Range Accuracy Resolution ±2%rdg±3dgt DC current 0.0A~1000A DC 0.1A ±2%rdg±3dgt AC current 0.0A~1000A AC 0.1A (Condition:23℃±5℃,below 75%rh,wire in the center of jaw) IV Technical Specifications Measurement of AC/DC current, Peak value hold, Function On-line monitoring Power Supply Zn-Mn dry battery,6F22,9V Test Mode...
  • Page 8: Structure

    Weight 180g(including the battery) Consumption 10mW ℃ Temperature and Working: -10℃~50 ,below 80%rh ℃ Humidity Storage: -10℃~60 ,below 70%rh Max error refer -10℃~0℃,40℃~50℃,Error will increase max to to environment 1%rdg Insulating AC2kV/rms (between the alloy of the clamp and the Strength housing) Applicable...
  • Page 9: Operating Method

    VII Operating Method 1. Start-up, Shutdown Press key to start up, LCD will begin to display; Press the POWER key again, the leaker will shut down. After starting up for 5 POWER minutes, LCD will flick notes that the leaker will shut down automatically; after flickering for 30s, it will shut down formally to reduce battery consumption.
  • Page 10: Current Measurement

    4. Current Measurement High voltage, extremely dangerous! Operators shall strictly observe safety rules; otherwise there would be risk of electric shock to cause personal injuries or casualties. Dangerous!Please don’t use it to measure current higher than 300A; otherwise there would be risk of electric shock to cause personal injuries or equipment damages.
  • Page 11: Peak Holding

    Attention! For your safety, when measuring heavy current, after confirmed the completion of correct operating test, please move the leaker away from measured conductor. In locations with difficulty to read out data, please use the data holding function. If [DH] symbol displayed, please discharge data holding state first, and then do the test.
  • Page 12: Data Upload

    2)Press keys to enter into data access mode and HOLD+POWER display Unit 1 storage data automatically; and then press HOLD again to turn the page of stored data; will display when there is NULL no data in stored in the memory, press key to exit data POWER access mode.
  • Page 13: Ⅸ Accessories

    ” symbol means the battery is undercharge and need to be 1)“ replaced. 2)Press key to shut down the leaker; before opening the battery POWER cover, please confirm the leaker is in off position, and then replace with qualified new battery; special attention shall be paid to polarity of battery;...
  • Page 16 Manufactured by ETCR Electronic Technology Co., Ltd Address: F-3F, No.4 Pengshang Zhifu Road, Jiahe, Baiyun District, Guangzhou, Guangdong, China Post Code: 510440 Tel: (86-20)62199556 62199553 Fax: (86-20)62199550 E-mail: info@etcr.cc Website: www.etcr.cc...
