CyberPower CSP600WSURC5 User Manual

6-Outlet Surge Protector 6-Outlet Surge Protector
(6 AC & 2 USB Ports) (6 AC & 2 USB Ports)
CSP600WSURC5 CSP600WSURC5
1
2
3
USER MANUAL
Copyright © 2018 Cyber Power Systems (USA), Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower CSP600WSURC5
Surge Protector. This manual explains the features and
operation of the CSP600WSURC5. Please take a few
moments to read this manual.
FEATURES
1. USB Charging Ports*
Connect and charge up to 2 USB devices using the
surge protected USB charging ports. One is type-C port
and the other is Type-A port.
*USB outlets cannot be used as a USB hub. This device
does not transfer data.
2. Pivoting Outlets
Pivoting outlets for ease of use and convenience.
3. Six Standard Outlets
4. Surge Protected Indicator
Illuminated when the surge protection feature is
working properly.
5. Ground Indicator LED
Illuminated when a properly grounded AC outlet
is detected.
6. Safe-fail Protection
1
Power is cut to connected equipment when the unit
can no longer provide surge protection.
2
SPECIFICATIONS
• Model Number: CSP600WSURC5
• Outlets: 6 standard outlets
3
• USB Charging Rating: 5 V/3.6 A total
• Surge Protection: 900 Joules
• Electrical Rating: 125 V/15 A/1875 W
• UL Clamping Voltage: UL 1449 4th/500 V (L-N, L-G, N-G)
• Maximum Peak Current: 45,000 A
4
• 3 AC Lines Protected: L-N: 15,000 A, L-G: 15,000 A,
5
N-G: 15,000 A
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 32 dB
• EMI/RFI Filtration: 150 kHz to 100 MHz
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only in
dry locations and only indoors. DO NOT plug into another
relocatable power tap. DO NOT "daisy chain" surge
protectors. DO NOT use with any aquarium equipment.
DO NOT use if properly grounded outlets are not
available. DO NOT install this device if there is less than 10
meters (30 feet) or more of wire between the electrical
outlet and electrical service panel. DO NOT use for
medical or life support equipment. This device features an
internal protection that will disconnect the surge protective
component at the end of its useful life, but it will maintain
unprotected power to the load.
TROUBLESHOOTING
▪
If the grounded indicator does not light when you plug in
the surge protector, move the surge protector to a di erent
grounded three-prong AC outlet. If it still does not light,
return the product to the retailer for assistance. If the surge
protector appears to be working properly, your outlets may
not be a properly grounded and need to be repaired by a
professional electrician. If the grounded indicator turns o
after a period of use, the surge protection has been
depleted. Replace your surge protector.
▪
If the protected indicator does not light, the surge
protector's AC lines are no longer protected from surge.
The surge protector may have received a power surge or
spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment as
designed, but it will not protect against future surges, and
spikes. It should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
Monday – Friday 7:00am – 6:00pm CST
