CyberPower CSP606U42A Quick Manual

8-Outlet Surge Protector 8-Outlet Surge Protector
(6 AC & 2 USB Ports) (6 AC & 2 USB Ports)
CSP606U42A CSP606U42A
1
2
PROTECTED
3
4.2A USB
4
USER MANUAL
Copyright © 2019 Cyber Power Systems (USA), Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower CSP606U42A
Surge Protector. This manual explains the features and
operation of the CSP606U42A. Please take a few
moments to read this manual.
FEATURES
1. ON/OFF Reset Switch Breaker
Controls power to all outlets. The switch is also a 15 A
breaker. When an overload occurs, it will automatically
switch o . To resume operation, ensure the overload
condition is removed and reset the surge protector by
switching the unit ON.
2. Surge Protected Indicator
Illuminated when the surge protection feature is
working properly.
3. Standard Grounded Outlets (6)
4. USB Charging Ports* (2)
Connect and charge up to two (2) USB devices using
the surge protected USB charging ports.
*USB outlets cannot be used as a USB hub. This device
does not transfer data.
5
5. Low-Profile Right-Angle Plug
6. Safe-fail Protection
Power is cut to connected equipment when the unit
can no longer provide surge protection.
SPECIFICATIONS
• Model Number: CSP606U42A
• Outlets: Standard Grounded Outlets (6), USB Charging
Ports (2)
• USB Charging Rating : 5 V/4.2A total
• Surge Protection: 900 Joules
• Electrical Rating: 125 V/15 A/1875 W
• UL Clamping Voltage: UL 1449 4th/500 V (L-N, L-G, N-G)
• Maximum Peak Current: 45,000 A
• 3 AC Lines Protected:
L-N: 15,000A
L-G: 15,000A
N-G: 15,000A
The maximum surge possible on household wiring is
6,000 volts)
• Response Time: Less than 1 nanosecond
• Circuit Breaker: Resettable 15 Amp
• Plug Type: Low-Profile, Right-Angle Plug
• Cord Length: 6 ft
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only in
dry locations and only indoors. DO NOT plug into another
relocatable power tap. DO NOT "daisy chain" surge
protectors. DO NOT use with any aquarium equipment.
DO NOT use if properly grounded outlets are not
available. DO NOT install this device if there is less than 10
meters (30 feet) or more of wire between the electrical
outlet and electrical service panel. DO NOT use for
medical or life support equipment. This device features an
internal protection that will disconnect the surge
protective component at the end of its useful life, but it
will maintain unprotected power to the load. If this
situation is undesirable for the application, follow the
manufacturer's instructions for replacing the device.
TROUBLESHOOTING
▪ If the ON/OFF is switched OFF, the 15 Amp circuit
breaker may have tripped. Examine your connected
equipment and remove the device that is overloading the
circuit. Then, turn the ON/OFF switch back to RESET.
▪ If the protected indicator does not light, the surge
protector's AC lines are no longer protected from surge.
The surge protector may have received a power surge or
spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment as
designed, but it will not protect against future surges,
and spikes. It should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
Monday – Friday 7:00am – 6:00pm CST
