CyberPower CSP604U User Manual

8-Outlet Surge Protector 8-Outlet Surge Protector
(6 AC & 2 USB Ports) (6 AC & 2 USB Ports)
CSP604U CSP604U
USER MANUAL
Copyright © 2019 Cyber Power Systems (USA), Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower CSP604U Surge
Protector. This manual explains the features and operation
of the CSP604U. Please take a few moments to read
this manual.
FEATURES
1. ON/OFF Reset Control Switch and Circuit Breaker
Controls power to all outlets. The switch is also a 15 A
breaker. When an overload occurs, it will automatically
switch o . To resume operation, ensure the overload
condition is removed and reset the surge protector by
switching the unit ON.
2. Surge Protected Indicator
Illuminated when the surge protection is working properly.
1
3. Standard Grounded Outlets (6)
4. USB Charging Ports* (2)
Connect and charge up to two (2) USB devices using
2
the surge protected USB charging ports.
*USB outlets cannot be used as a USB hub. This device
does not transfer data.
SPECIFICATIONS
• Model Number: CSP604U
• Outlets: Standard Grounded Outlets (6), USB Charging
Ports (2)
• Surge Protection: 1,200 Joules
• Electrical Rating: 125 V/15 A/1875 W
• UL Clamping Voltage: UL 1449 3rd/400 V (L-N, L-G, N-G)
3
• Maximum Peak Current: 60,000 A
• 3 AC Lines Protected:
L-N: 30,000 A
L-G: 15,000 A
N-G: 15,000 A
(The maximum surge possible on household wiring is
6,000 volts)
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 32 dB
• USB Charging Rating: 5 V/2.4A total
• Circuit Breaker: Resettable 15 Amp
• EMI/RFI Filtration: 150 kHz to 100 MHz
4
• Power Cord Length: 4 ft
• Plug Type: Low Profile Right Angle Plug
• Keyhole Mounting Slots: Yes
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only in
dry locations and only indoors. DO NOT plug into another
relocatable power tap. DO NOT "daisy chain" surge
protectors. DO NOT use with any aquarium equipment.
DO NOT use if properly grounded outlets are not
available. DO NOT install this device if there is less than 10
meters (30 feet) or more of wire between the electrical
outlet and electrical service panel. DO NOT use for
medical or life support equipment. This device features an
internal protection that will disconnect the surge protective
component at the end of its useful life, but it will maintain
unprotected power to the load. If this situation is undesirable
for the application, follow the manufacturer's instructions for
replacing the device.
TROUBLESHOOTING
▪ If the ON/OFF is switched OFF, the 15 Amp circuit
breaker may have tripped. Examine your connected
equipment and remove the device that is overloading the
circuit. Then, turn the ON/OFF switch back to RESET.
▪ If the protected indicator does not light, the surge
protector's AC lines are no longer protected from surge.
The surge protector may have received a power surge or
spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment as
designed, but it will not protect against future surges,
and spikes. It should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
1
Monday – Friday 7:00am – 6:00pm CST
