Operating Instructions
Type 900 Series
Electrode Stabilization Ovens
• Bench models provide large capacity storage for electrodes
• Door mounted thermometer offered for instant temperature indication
• Adjustable thermostatic control
• Single action door latch easily closes and can be locked
• Shelving provides fit for 50 lb cans
Part No. Description
Type 900 Series Ovens with 10"
grounded heavy duty cord
1200300 240/480V AC at 2400 watts
240/480V AC at 2400 watts with door
1200301
mounted thermometer installed
* Operation on Direct Current (DC) will damage oven and void warranty. Average stabilized termperature at 70
Ovens
Temperature Range*
(no plug)
100 - 550 F
° °
(38 - 288 C) +/-25 F (14 C)
° ° ° °
adjustable thermostat control
with indicator light
dryrod.com info@dryrod.com +1 414.973.3400 8711 West Port Avenue Milwaukee, WI 53224 Phoenix International
Capacity
Insulation Chamber Size
(for 18" electrodes)
1100 lb (499 kg)
2" 30" diameter
Accepts electrodes
fiberglass x 27" deep
up to 24"
F ambient temperature.
°
Weight Dimensions
327 lb 43" x 43" x 45"
(148 kg) (109.2 x 109.2 x 114.3 cm)
