Operating Instructions
Type 200HT Series
Electrode Stabilization Ovens
• High temperature oven
• Door mounted thermometer
• Variable high temperature for rebaking and reconditioning
Part No.
Description
Type 200HT Series Ovens with Wheels
120/240V AC at 1500 watts
1200461
with installed thermometer
* Operation on Direct Current (DC) will damage oven and void warranty. Average stabilized termperature at 70
Ovens
Temperature Range*
Insulation
100
- 660
F
°
°
(38
°
- 350
°
C) +/-25
°
F (14
°
C)
fiberglass
adjustable thermostat control
with indicator light
dryrod.com info@dryrod.com +1 414.973.3400 8711 West Port Avenue Milwaukee, WI 53224 Phoenix International
Capacity
Chamber Size
(for 18" electrodes)
2"
14.5" x 17" x 18"
200 lb (90.7 kg)
F ambient temperature.
°
Weight
Dimensions
90 lb
22" x 23.75" x 25"
(41 kg)
(55.9 x 60.3 x 63.5 cm)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DryRod 200HT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Phoenix International DryRod 200HT Series

  • Page 1 * Operation on Direct Current (DC) will damage oven and void warranty. Average stabilized termperature at 70 F ambient temperature. ° dryrod.com info@dryrod.com +1 414.973.3400 8711 West Port Avenue Milwaukee, WI 53224 Phoenix International...
  • Page 2: Temperature Settings

    Spread the electrodes evenly, allowing space over each shelf temperatures, found at www.dryrod.com/guide. for air circulation required to remove excess moisture. The maximum suggested layer depth on any shelf is 5 inches. Phoenix International 8711 West Port Avenue Milwaukee, WI 53224 +1 414.973.3400 info@dryrod.com dryrod.com...
  • Page 3 Item No. Spare Part Description Part No. per 10 Ovens Heating Element Kit 1257096 Door Latch and Strike 1252200 North American Power Cord 1257540 Thermostat Kit 1257085 dryrod.com info@dryrod.com +1 414.973.3400 8711 West Port Avenue Milwaukee, WI 53224 Phoenix International...
  • Page 4: Ordering Information

    1255150 Shelving Assembly Gasket Kit 1257163 Gasket (per foot) Power Inlet Kit 1257390 Rivet Locking Power Inlet Hinge Kit 1250206 (2 hinges) North American Power Cord 1257540 Phoenix International 8711 West Port Avenue Milwaukee, WI 53224 +1 414.973.3400 info@dryrod.com dryrod.com...
  • Page 5 Replacement Parts 1 Door Latch and Strike 4 Vent Cover Kit 2 North American Locking Power Connection Kit 3 Indicator Light 6 Heating Element Kit 5 Thermometer Kit dryrod.com info@dryrod.com +1 414.973.3400 8711 West Port Avenue Milwaukee, WI 53224 Phoenix International...
  • Page 6 Warranty Phoenix Ovens International LLC warrants its products against defects in material and workmanship. The company will, at its discretion, repair or replace any properly installed Phoenix International manufactured product which fails under normal operating conditions within one year from date of receipt. Contact the factory for return authorization before returning the product to Phoenix International freight prepaid.
