Summary of Contents for Schiller Grounds Care Classen TRS-20HE
- Page 1 TRS-20HE / TRS-20BE TURF RAKE (Serial No. 001000 & UP) TSS-20HE / TSS-20BE TURF SEEDER (Serial No. 001000 & UP) OPERATORS MANUAL C100540 Schiller Grounds Care, Inc. 1028 Street Road • Southampton, PA 18966 Telephone: 1-800-366-6268...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........3 Thank You ...............3 Read This Manual ............3 Warranty ..............3 Measurements ............3 Serial Numbers ............3 Ordering Parts ............3 Directions ..............3 Pre-Delivery Check List ..........4 Delivery Check List ..........4 Owner’s Record ............4 SAFETY PRECAUTIONS ......5 Training ..............5 Preparation Safety ............5 Engine Safety ............5... -
Page 3: Introduction
INTRODUCTION THANK YOU MEASUREMENTS Thank you for purchasing a CLASSEN TRS-20E/ U.S. Units of measure are used in this manual. TSS-20E. SERIAL NUMBERS READ THIS MANUAL Write frame and engine serial numbers, plus model Read this manual carefully in its entirety. It contains numbers in “Owner’s Record”... -
Page 4: Pre-Delivery Check List
Add engine oil (refer to Engine manual) and correctly. Add fuel, start engine, test run. 10. Schiller Grounds Care, Inc. parts and service. 11. Give the customer the Operator’s Manual and DATE SET UP __________/__________/________ encourage customer to read it. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS TRAINING Fill the fuel tank outdoors. Regard the unit as a piece of power equipment and teach this regard to all who If fuel is spilled, do not attempt to start the operate this unit. engine. Move away from the area of the spill Read the instructions carefully. -
Page 6: Operation
14. Stop the engine and disconnect the spark plug STARTING ENGINE wire: Turn fuel cock to the “open” position a) before checking, cleaning or working Turn choke on (closed). on unit Turn ignition switch to “on”. b) after striking a foreign object (inspect the unit for damage and make repairs before Move throttle control to high RPM setting. -
Page 7: Optional Blade Assemblies
OPTIONAL BLADE REPLACING SHAFT ASSEMBLY ONLY ASSEMBLIES If replacing the existing shaft assembly, only follow steps 1 through 3 above. Proceed with the following CHANGING BLADE ASSEMBLIES steps. Within minutes your machine can be converted to a Remove the two drive pulleys and bearing turf rake, turf seeder or turf slicer by purchasing the plates from the main shaft (one on each optional blade assemblies available complete with... - Page 8 Seeding/Multipurpose Height The seeding/multipurpose blades are used for cutting grooves for over-seeding and can also be used for verticutting grasses. To set the height properly place unit on the lawn surface and adjust the wheel height up (see Fig. 4 ). Adjusting the wheel height up lowers the blades.
-
Page 9: General Maintenance
GENERAL to one side and keep feet and hands clear while making adjustments. MAINTENANCE MACHINE STORAGE TO KEEP THE TRS-20E/TSS-20E IN GOOD OPERATING CONDITION, STORAGE INSTRUCTIONS PERFORM THE FOLLOWING: SAFETY WARNING • When replacement parts are required, use genuine Classen parts or parts with TO PREVENT POSSIBLE EXPLOSION OR equivalent characteristics including type, IGNITION OF VAPORIZED FUEL, DO NOT... -
Page 10: Care For Hydraulic System
CARE FOR HYDRAULIC SYSTEM To keep the hydraulic system in working order, Adjust control linkage such that there are a few steps needed to take place. If transmission control is stroking synthetic oil were used we would suggest a full full forward. -
Page 15: Declaration Of Conformity
EC Declaration of Conformity The Undersigned Manufacturer: Schiller Grounds Care, Inc. 1401 Logan Street Chuck Clark Director of Operations Norfolk, NE 68701 Date: March 8, 2011 EU Authorized Representative: Earlsmere Limited Unit 18 Valley Road Jim White Station Road Industrial Estate... -
Page 16: Warranty
The User is responsible for damage due to improper operation and maintenance, as well as abuse. All claims must be received by the factory 30 days after the end of the warranty period to receive warranty consideration. © 2010 Schiller Grounds Care, Inc. All Rights Reserved. 6/10... - Page 17 Classen, or its distributors and dealers, accept no responsibility for variations which may be evident in the actual specifications of its products and the statements and descriptions contained in this publication. © 2007 Schiller Grounds Care, Inc. 02/2011...
