Hardware Inventory

Separate all hardware and group as shown below for the assembly and installation procedures.
Bolt
1/4-20x1-3/4" (8)
Carriage Bolt
Wing Nut
1/4"-20x1/2" (2) 1/4"-20 (2)
Lag Screw
5/16"-9x1-5/8" (2)
Lag Screw
5/16"-18x1-7/8" (2)
Carriage Bolt
5/16"-18x2-1/2" (2)
Clevis Pin
5/16"x2-3/4" (1)

ASSEMBLY HARDWARE

Hex Bolt
1/4"-20x5/8" (4)

INSTALLATION HARDWARE

Ring
Fastener (3)
Hex Bolt
5/16"-18x7/8" (4)
Screw
6ABx1-1/4" (2)
Drywall Anchors (2)
Clevis Pin
5/16"x1" (1)
7
Lock Nut
1/4"-20x7/16 (12) Sprocket Coupling Sleeve
Nut 5/16"-18 (6)
Insulated
Lock Washer 5/16" (6) Staples (30)
Screw 6-32x1" (2)
Handle
Rope
Clevis Pin
5/16"x1-1/4" (1)
