Chamberlain Security+ 9500-3K Owner's Manual

Chamberlain Security+ 9500-3K Owner's Manual

1/2 hp
Hide thumbs
Table of Contents

Advertisement

Quick Links

Please read this manual and the enclosed safety materials carefully!
Fasten the manual near the garage door after installation.
The door WILL NOT CLOSE unless the Protector System
properly aligned.
Periodic checks of the opener are required to ensure safe operation.
The model number label is located under the light lens on the side panel of
your opener.
Garage Door Opener
Model 9500-3K
1/2 HP
For Residential Use Only
Owner's Manual
The Chamberlain Group, Inc.
A DUCHOSSOIS ENTERPRISE
845 Larch Avenue
Elmhurst, Illlinois 60126-1196
www.chamberlaingroup.com
Complies with UL 325
Regulations effective
January 1, 1993.
®
®
®
is connected and
