Summary of Contents for Hytera E-center
- Page 1 E-center User Manual...
- Page 2 Preface Thank you for purchasing our product. This user manual is a quick guide on how to use it. This manual is applicable to the following product: E-center Portable Command Center...
- Page 3 Note: Indicates references that can further describe the related topics. Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names.
- Page 4 To ensure optimal performance and compliance with the uncontrolled environment RF energy exposure limits in the above standards and guidelines.
-
Page 5: Table Of Contents
3.4 Connecting the Cables ........................8 4. Basic Operations ..........................10 4.1 Unfolding E-center ........................10 4.2 Turning On the E-center ....................... 10 4.3 Turning Off the E-center ....................... 10 5. Basic Services ..........................11 5.1 Call Services ..........................11 5.2 Topology Manager ........................ -
Page 6: Packing List
The figures in this manual are for reference only. Main Unit Part Qty. Part Qty. Main unit User manual Mandatory Accessories Note To ensure normal use of E-center, the accessories listed in the following table are mandatory. Part Qty. Part Qty. Battery Power adapter (including three cables) -
Page 7: Product Overview
2. Product Overview Main Unit Front and Rear Views... - Page 8 Top View Left and Right Views Part Name Description Left screen Size: 15.6", resolution: 1920x1080...
- Page 9 Part Name Description Resolution: Megapixel, 1920x1080 (max); specific Camera parameters are subject to the actual product. Middle screen Size: 15.6", resolution: 1920x1080 Right screen Size: 15.6", resolution: 1920x1080 Battery 13.6 V DC Battery latch Flashes green every 0.5 second: The device is ...
- Page 10 Part Name Description Right screen Enables the right screen to enter or exit the power saving power-saving button mode. Power switch Powers on/off the device. The 3-axis joystick is used to control the monitor angle of an external PTZ camera. You can move the joystick up and down Camera joystick to control the pan, left and right to control the tilt, and rotate the knob to control the zoom.
-
Page 11: Power Adapter
Power Adapter Part Name Description AC power inlet Connects to the AC power cord. DC power inlet Connects to the DC power cord. Connects to the power inlet on the main unit or to the charging Output connector port of the battery. -
Page 12: Preparation
3. Preparation Note The figures in this manual are for reference only. Attaching the Battery On the back of the main unit, push the two battery latches to the middle at the same time and pull the back cover downwards. Press OPEN to unleash the latch;... -
Page 13: Charging
A standard SIM card is required if you want to carry services over a 3G/4G link. The GMS link is used to call the mobile; while the 3G/4G link is used to transmit data. To call the mobile, the main unit must be equipped with Hytera dispatch software. Insert the standard SIM card into the corresponding slot. -
Page 15: Basic Operations
When folding the E-center screens, fold the left screen first and then the right screen; otherwise, the screens may be damaged. Turning On the E-center Press and hold the power switch for 3 seconds to turn the E-center on. If the RUN indicator flashes green every 1 seconds, the E-center runs normally. Note If the device is installed with a battery, it is powered by the battery. -
Page 16: Basic Services
You are advised not to close the E-CenterTableTool; otherwise, some functions may be exceptional or unavailable. After the E-center is turned on, the following interface appears at the lower right corner of the middle screen. The following table describes the meanings of the respective icons. - Page 17 Icon Status Description : Microphone is not connected. : Microphone is connected. : Charging. : The battery level is lower than 14%. : The battery level is between 15% and 29%. : The battery level is between 30% and 54%. ...
-
Page 18: Troubleshooting
6. Troubleshooting Phenomena Possible Cause Solution The cable connection is Ensure that the power cord is connected properly. The device fails improper or the battery runs to be turned on. Make sure that the battery level is at least 5%. out. -
Page 19: Care And Cleaning
7. Care and Cleaning To guarantee optimal performance as well as a long service life of the product, please follow the tips below. Care Do not pierce, strike, throw, or scrape the product. Keep the product away from substances that can corrode its circuitry. ... -
Page 20: Optional Accessories
8. Optional Accessories For details about main accessories for the product, contact your local dealer or call 400-830-7020. Caution Use the accessories specified by the Company only. Otherwise, the Company shall not be liable for any loses or damages arising out of use of unauthorized accessories. -
Page 21: Warranty
9. Warranty Commencing on the date of purchase and within the contract warranty obligations, Hytera will be responsible for any faulty parts under normal use and service. Main unit 12 months Battery 12 months Power adapter 12 months... - Page 22 (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement is the trademark or registered trademark of Hytera Communications Corporation Limited. 2019 Hytera Communications Corporation Limited. All Rights Reserved.
