Location of controls
1) Leather handle
2) Memory button
3) Repeat/Ran button
4) Function button
5) Volume up/down knob
6) On/standby button
7) Mute button
8) Source button
9) Folder down/Alarm button
10) Folder up/Clk adj
/
11) Skip up
down
12) Tuning knob
13) Play/pause
button
14) Stop
button
15) Snooze button
16) LCD display
17) USB socket
18) 3.5mm headphone jack
19) SD card slot
20) CD door open/close
21) Remote sensor
22) Dial pointer
23) FM-stereo LED indicator
24) Tuner LED indicator
25) Alarm sound mode selector
26) Rod antenna
27) Band switch
28) AC socket
29) Battery compartment (main unit)
30) Battery compartment (clock back up)
Caution:
Usage of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service personnel.
Precautions for use
Installation
Unpack all parts and remove protective material.
•
Do not connect the unit to the mains before checking the main voltage and before all other connections have been
•
made.
Do not cover any vents and make sure that there is a space of several centimeters at the back of the unit for
•
ventilation.
AC connection
1.
Connect the one end of the detachable power cord to the AC socket (28) and the other end to the ac outlet.
2.
When you first plug the unit into the mains, the unit will go into standby mode.
3.
Turn on the unit by On/Standby button (6), the TUNER LED indicator (24) will light up.
DC
connection
For DC operation, please insert 6 pcs size C (UM-2) battery at batter compartment (29) as below direction:-
button
1
